1991 1993 Nevada 750 Electrical System
| Position | Part Number | Description |
|---|---|---|
| 1 | 31747160 | #01 Electrical system (#31747160) |
| 1 | 31747161 | #01 Electrical system (#31747161) |
| 2 | 31747260 | #02 Dashboard cable (#31747260) |
| 3 | 31747360 | #03 Taillight wiring harn. (#31747360) |
| 4 | 29725850 | ALTERNATOR HARNESS (#29725850) |
| 5 | 27743050 | FUSEBOX A (#27743050) |
| 6 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 7 | 29748550 | CABLE (#29748550) |
| 8 | 31722140 | #16 H.T. wiring (#31722140) |
| 9 | 27721435 | #09 Electronic control unit (#27721435) |
| 10 | 27723835 | SUPPORT (#27723835) |
| 11 | 27710435 | CONDENSER A (#27710435) |
| 12 | 18759550 | CABLE (#18759550) |
| 13 | 30732510 | RELAY (#30732510) |
| 14 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 15 | 28732560 | RELAY (#28732560) |
| 16 | 31724540 | #16 Neutral sensor cable (#31724540) |
| 17 | 14609650 | TIE WRAP (#14609650) |
| 18 | 98202516 | SCREWS (#98202516) |
| 19 | 95100059 | WASHER (#95100059) |
| 20 | 92630105 | NUT (#92630105) |
| 21 | 29448750 | #21 Plate (#29448750) |
| 22 | 31704061 | #15 Relais support (#31704061) |
| 23 | 31746361 | #23 Fusebox plate (#31746361) |
