1991 1993 Nevada 750 Foot Rests
| Position | Part Number | Description |
|---|---|---|
| 1 | 23446010 | #01 LH footrest support (#23446010) |
| 2 | 23443510 | #02 RH footrest support (#23443510) |
| 3 | 14615901 | WASHER (#14615901) |
| 4 | 98622416 | SCREW (#98622416) |
| 5 | 29436450 | BUSHING (#29436450) |
| 6 | 66441730 | PLATE (#66441730) |
| 7 | 95021108 | WASHER (#95021108) |
| 8 | 61270300 | WASHER (#61270300) |
| 9 | 92630508 | NUT (#92630508) |
| 10 | 98250835 | Screw (#98250835) |
| 11 | 90280006 | E CLIP (#90280006) USE 005965 |
| 12 | 66440630 | PIN (#66440630) |
| 13 | 66440730 | RH front foot rest pipe (#66440730) |
| 14 | 66441830 | LH Foot Rest Arm (#66441830) |
| 15 | 66441630 | Special Washer (#66441630) |
| 16 | 51609800 | SPRING WASHER (#51609800) |
| 17 | 66443230 | Rear Foot Peg (#66443230) |
| 18 | 31441260 | PLATE (#31441260) |
| 19 | 98304014 | #19 Screw (#98304014) |
| 20 | 93180206 | RUBBER PLUG (#93180206) |
| 21 | 23943410 | CHROME PLUG (#23943410) |
