1992 1993 Nevada 350 Front Rear Mudguards
| Position | Part Number | Description |
|---|---|---|
| 1 | 274344201 | #01 Front mudguard blank (#274344201) |
| 1 | 31434381 | Front mudguard (#31434381) |
| 1 | 31434382 | Front mudguard (#31434382) |
| 2 | 27436920 | #02 Splash guard (#27436920) |
| 3 | 98230845 | ALLEN BOLT (#98230845) |
| 4 | 90706092 | O RING (#90706092) |
| 5 | 31436415 | SPACER A (#31436415) |
| 6 | 31659760 | Cable-guide (#31659760) |
| 7 | 31479560 | #07 Splash guard (#31479560) |
| 8 | 31479760 | #08 Cover (#31479760) |
| 9 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 10 | 19705900 | PLUG (#19705900) |
| 11 | 314370801 | #09 Rear mud'ard (#314370801) |
| 11 | 31437081 | #09 Rear mud'ard (#31437081) |
| 11 | 31437082 | Rear mudguard (#31437082) |
| 12 | 31439160 | #10 Rear mud'ard supp. (#31439160) |
| 13 | 31457860 | #13 RH rear cover chromate (#31457860 ) |
| 14 | 31459160 | #14 LH rear cover chromate (#31459160) |
| 15 | 31575560 | #15 Plate (#31575560) |
| 16 | 31438060 | #16 Rear mudg. extension (#31438060) |
| 17 | 39474600 | NUMBER PLATE HOLDER (#39474600) |
| 18 | 31745860 | REFLEX REFLECTOR (#31745860) |
| 19 | 98622216 | ALLEN BOLT (#98622216) |
| 20 | 92630105 | NUT (#92630105) |
| 21 | 98054212 | BOLT (#98054212) |
| 22 | 90706035 | GROMMET (#90706035) |
| 23 | 95000205 | WASHER (#95000205) |
| 24 | 98054312 | BOLT (#98054312) |
| 25 | 93301175 | CABLE CLAMP (#93301175) |
| 26 | 95100141 | WASHER (#95100141) |
| 27 | 98054320 | BOLT (#98054320) |
| 28 | 95000206 | WASHER (#95000206) |
| 29 | 93110060 | RUBBER WASHER (#93110060) |
| 30 | 95100120 | WASHER (#95100120) use 95105320 |
| 31 | 92630206 | NUT (#92630206) |
| 32 | 92660601 | CAGE NUT (#92660601) |
| 33 | 31900060 | #10 Operator's handbook (#31900060) |
| 33 | 31900061 | #10 Operator's handbook (#31900061) |
| 34 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 35 | 98054325 | BOLT (#98054325) |
| 36 | 92630106 | NUT USE 92630707 (#92630106) |
| 38 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 39 | 92781062 | NUT (#92781062) |
| 40 | ||
| 41 | 98054318 | BOLT (#98054318) |
| 42 | 28436460 | BUSHING A (#28436460) |
| 43 | 29579460 | GASKET (#29579460) |
