1992 1994 750x Polizia pa 1a Serie 750 Electrical System
| Position | Part Number | Description |
|---|---|---|
| 1 | 31747130 | #01 Main wiring harness (#31747130) |
| 2 | 14747455 | CABLE ASSY (#14747455) |
| 3 | 31747230 | #03 Instrum.board cable kit (#31747230) |
| 4 | 27725810 | WIRING HARNESS (#27725810) |
| 4 | 27725820 | #18 Alternator-regulator wiring (#27725820) |
| 5 | 31722130 | #05 H.T. wiring (#31722130) |
| 6 | 23721493 | ECU elettronica (#23721493) |
| 7 | 27723835 | SUPPORT (#27723835) |
| 8 | 27710435 | CONDENSER A (#27710435) |
| 9 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 10 | 19732500 | HORN, HL OR STARTER RELAY (#19732500) |
| 11 | 30743000 | FUSE BOX ASSY A (#30743000) |
| 12 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 13 | 31747330 | #23 Taillight wiring harn. (#31747330) |
| 14 | 28747960 | GROUND STRAP (#28747960) |
| 15 | 39741150 | #29 Brake light switch (#39741150) |
| 16 | 92700071 | NUT (#92700071) |
| 17 | 98054220 | BOLT (#98054220) |
| 18 | 95100059 | WASHER (#95100059) |
| 19 | 95000205 | WASHER (#95000205) |
| 20 | 92630205 | LOCK NUT (#92630205) |
| 21 | 98054212 | BOLT (#98054212) |
| 22 | 31759230 | #22 Wire (#31759230) |
| 23 | 23726300 | #23 Alternator wiring BOSCH (#23726300) |
| 24 | 28727200 | RESISTANCE (#28727200) |
| 25 | 18759550 | CABLE (#18759550) |
| 26 | 98054314 | SCREW (#98054314) |
| 27 | 95000206 | WASHER (#95000206) |
| 28 | 95021106 | WASHER, WAVE (#95021106) |
| 29 | 14609650 | TIE WRAP (#14609650) |
| 29 | 61609630 | #26 Hose clamp (#61609630) |
