1992 1994 750x Polizia pa 1a Serie 750 Front Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 314343301 | #01 Front mudguard (#314343301) |
| 1 | 31434335 | #01 Front mud'ard (#31434335) |
| 1 | 31434336 | #01 Front mud'ard (#31434336) |
| 2 | 31436635 | #02 U-bolt (#31436635) |
| 2 | 31436636 | #02 U-bolt (#31436636) |
| 3 | 27436875 | #03 Spacer (#27436875) |
| 3 | 31436835 | #03 Spacer (#31436835) |
| 4 | 98052350 | BOLT (#98052350) |
| 5 | 95000206 | WASHER (#95000206) |
| 6 | 95100121 | WASHER (#95100121) |
| 7 | 92630106 | NUT USE 92630707 (#92630106) |
| 8 | 31584530 | #08 RH protection (#31584530) |
| 8 | 31584535 | #08 RH protection (#31584535) |
| 9 | 31584435 | #09 Front disc 'ard (#31584435) |
| 9 | 31584436 | #09 Front disc 'ard (#31584436) |
| 10 | 98230616 | SCREW (#98230616) |
| 11 | 98230622 | ALLEN SCREW (#98230622) |
| 12 | 66478610 | WASHER (#66478610) |
| 13 | 93110060 | RUBBER WASHER (#93110060) |
| 14 | 31584630 | #14 Plate (#31584630) |
| 15 | 27651315 | #15 Hose clamp (#27651315) |
| 16 | 17658260 | RUBBER RING (#17658260) |
| 17 | 61013800 | SPRING WASHER (#61013800) |
| 18 | 98612312 | ALLEN BOLT (#98612312) |
| 19 | 31583935 | #19 Lock plate (#31583935) |
| 20 | 92630206 | NUT (#92630206) |
