1992 1994 750x Polizia pa 1a Serie 750 Rear Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| 1 | 27677015 | Brake lever (#27677015) |
| 2 | 27251015 | #02 Rubber spacer (#27251015) |
| 3 | 27667515 | #03 Lever (#27667515) |
| 4 | 31667635 | #04 Spring (#31667635) |
| 5 | 27675015 | #05 Pump rod (#27675015) |
| 6 | 27667015 | #06 Rear master cylinder (#27667015) |
| 7 | 27668015 | #07 Union (#27668015) |
| 8 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 9 | 95990027 | HOLLOW SCREW (#95990027) |
| 10 | 65663500 | BRAKE RESERVOIR (#65663500) |
| 11 | 17661052 | MASTER CYLINDER LID W/ BELLOWS (#17661052) |
| 12 | 00823950050 | TUBE (#00823950050) |
| 13 | 19157800 | CLAMP COMPLETE (#19157800) |
| 14 | 27659515 | Rear brake pump union (#27659515) |
| 15 | 91181114 | SPACER (#91181114) |
| 16 | 27530593 | #16 ard (#27530593) |
| 17 | 98620345 | SCREW (#98620345) |
| 18 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 19 | 95129260 | SPRING WASHER (#95129260) |
| 20 | 98074320 | SCREW (#98074320) |
| 21 | 92601206 | NUT (#92601206) |
| 22 | 98072330 | SCREW (#98072330) |
| 23 | 95000206 | WASHER (#95000206) |
| 24 | 95021106 | WASHER, WAVE (#95021106) |
| 26 | 98054214 | BOLT (#98054214) |
| 27 | 95100059 | WASHER (#95100059) |
| 28 | 19718000 | CLAMP (#19718000) |
| 29 | 23093300 | #29 Protection collar (#23093300) |
