1992 1995 Daytona 1000 Drive Shaft
| Position | Part Number | Description |
|---|---|---|
| 1 | 30060100 | CYL/PISTON ASSY (#30060100) |
| 1 | 30350202 | Rear Drive Assy (#30350202) |
| 2 | 30060400 | PISTON BARE (#30060400) |
| 2 | 30329502 | DRIVESHAFT ASSY C (#30329502) |
| 3 | 30060600 | RING SET (#30060600) |
| 3 | 98832430 | ALLEN BOLT (#98832430) |
| 4 | 30060700 | PISTON RING (#30060700) |
| 4 | 30211700 | CLAMP A (#30211700) |
| 5 | 30060900 | PISTON RING (#30060900) |
| 5 | 98612216 | ALLEN BOLT (#98612216) |
| 6 | 29217960 | WASHER (#29217960) |
| 6 | 30061000 | PISTON RING (#30061000) |
| 7 | 28037460 | OUTER VALVE SPRING (#28037460) |
| 7 | 30061241 | WRIST PIN (#30061241) |
| 8 | 90351038 | CIRCLIP (#90351038) |
| 9 | 14615901 | WASHER (#14615901) |
| 9 | 91111113 | DOWEL (#91111113) |
| 10 | 30020800 | DAYTONA BASE GSKT (#30020800) |
| 10 | 30334600 | SPACER A (#30334600) |
| 11 | 30021700 | STUD LONG (#30021700) |
| 11 | 30358902 | REACTION ROD (#30358902) |
| 12 | 30061500 | CON ROD ASSY C (#30061500) |
| 12 | 92602212 | NUT (#92602212) |
| 13 | 30359200 | BALL JOINT (#30359200) |
| 13 | 91112128 | BUSH-CON ROD (#91112128) |
| 14 | 30062260 | CON ROD BOLT (#30062260) |
| 14 | 30636700 | BUSHING (#30636700) |
| 15 | 30357800 | PIVOT PIN A (#30357800) |
| 15 | 92731090 | NUT (#92731090) |
| 16 | 30062000 | ROD BRG HALF STD (#30062000) USE 01062030 |
| 16 | 30062001 | HALF BEARING 1ST (#30062001) |
| 16 | 30062002 | ROD BRG 2ND (#30062002) |
| 16 | 30062003 | ROD BRG 3RD (#30062003) |
| 16 | 95000210 | WASHER (#95000210) |
| 17 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 17 | 29064161 | #01 Drive shaft (#29064161) |
| 18 | 12065400 | CRANK PLUG (#12065400) |
| 18 | 92630410 | NUT A (#92630410) |
| 19 | 30067006 | DAYTONA FLYWHEEL 4 1/2 #'S (#30067006) |
| 19 | 30357700 | PIVOT PIN A (#30357700) |
| 20 | 14615901 | WASHER (#14615901) |
| 20 | 95100303 | SPACER A (#95100303) |
| 21 | 12067701 | SCREW (#12067701) use 597150 |
| 22 | 30067901 | DAYTONA RING GEAR 3 1/4 # (#30067901) |
| 23 | 98054420 | BOLT (#98054420) |
