1992 1995 Daytona 1000 Rear Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 37677005 | BRAKE LVR ASSY A (#37677005) |
| 2 | 28252060 | BUSHING (#28252060) |
| 3 | 14251001 | SHIFT AND BRAKE PEDAL RUBBER (#14251001) |
| 4 | 98230616 | SCREW (#98230616) |
| 5 | 30676600 | PIN (#30676600) |
| 6 | 90706141 | O RING (#90706141) USE 847180 |
| 7 | 95100343 | WASHER (#95100343) |
| 8 | 30677600 | ECCENTRIC (#30677600) |
| 9 | 98622325 | BOLT CHROME (#98622325) |
| 10 | 30675300 | BALL JOINT (#30675300) |
| 11 | 92601206 | NUT (#92601206) |
| 12 | 30675200 | BRAKE ROD (#30675200) |
| 13 | 98622320 | SCREW (#98622320) |
| 14 | 92630206 | NUT (#92630206) |
| 15 | 30666900 | MASTER CYLINDER (#30666900) |
| 16 | 30530525 | MASTER CYL LID KIT (#30530525) |
| 17 | 19659500 | REV KIT (#19659500) |
| 18 | 30665400 | MASTER CYL GUARD A (#30665400) |
| 19 | 98230620 | ALLEN BOLT (#98230620) |
| 20 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 21 | 30657500 | BRAKE HOSE REAR A (#30657500) |
| 22 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 23 | 14657050 | SWITCH (BRAKE) (#14657050) |
| 24 | 12006500 | BAND (#12006500) |
| 25 | 98054310 | ADJ. BOLT (#98054310) |
| 26 | 95004206 | WASHER (#95004206) |
| 27 | 49609601 | TIE STRAP (#49609601) |
| 28 | 00823950050 | TUBE (#00823950050) |
| 29 | 19157800 | CLAMP COMPLETE (#19157800) |
| 30 | 30663500 | BRAKE RESERVOIR (#30663500) |
| 31 | 30661101 | RESERVOIR CAP (#30661101) |
| 32 | 98612316 | ALLEN BOLT (#98612316) |
| 33 | 30635800 | BRACKET A (#30635800) |
| 34 | 30636100 | BUSHING A (#30636100) |
| 35 | 90706253 | O RING (#90706253) |
| 36 | 30634201 | BUSHING A (#30634201) |
| 37 | 30636600 | ROD BARE (#30636600) |
| 38 | 92602208 | NUT (#92602208) |
| 39 | 30638100 | BALL JOINT (#30638100) |
| 40 | 98150455 | ALLEN BOLT A (#98150455) |
| 41 | 14615901 | WASHER (#14615901) |
| 42 | 92630108 | NUT 8MM (#92630108) |
| 43 | 98150440 | ALLEN BOLT (#98150440) |
| 44 | 30653001 | CALIPER - REAR (#30653001) USE AP8213196 |
| 45 | 98602425 | ALLEN BOLT A (#98602425) |
| 46 | 95990028 | SCREW (#95990028) |
| 47 | 27654610 | PAD SET (#27654610) |
| 48 | 30654700 | CALIPER COVER (#30654700) |
| 49 | 30659101 | PIN KIT A (#30659101) |
| 50 | 31659260 | BLEEDER SCREW KIT(#31659260) |
| 51 | 30636500 | ROD ASSY A (#30636500) |
