1992 1997 Quota 1000 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 30500630 | UPPER H-BAR CLAMP (#30500630) |
| 2 | 66530505 | ALLEN BOLT (#66530505) USE 98682430 |
| 3 | 30530544 | SCREW (#30530544) |
| 4 | 30500230 | LOWER H/BAR CLAMP (#30500230) |
| 5 | 27530503 | RUBBER SLEEVE A (#27530503) |
| 6 | 27530504 | TUBE (#27530504) |
| 7 | 27530505 | WASHER (#27530505) USE AP8123511 |
| 8 | 27530506 | NUT (#27530506) |
| 9 | 98622435 | ALLEN BOLT (#98622435) |
| 10 | 30493130 | UPPER TRIPLE CLAMP (#30493130) |
| 11 | 30530541 | FORK GAITER EACH (#30530541) |
| 12 | 30530542 | FORK CAP (#30530542) |
| 13 | 30530508 | O RING (#30530508) |
| 14 | 30530551 | Pipe (#30530551) |
| 15 | 30494030 | #15 Lower plate (#30494030) |
| 16 | 30512830 | NUT (#30512830) |
| 17 | 27530510 | WASHER (#27530510) |
| 18 | 27530511 | LOCK NUT (#27530511) |
| 19 | 98620335 | SCREWS (#98620335) |
| 20 | 30525331 | LH hub (#30525331) |
| 21 | 30525330 | RH hub (#30525330) |
| 22 | 30530515 | LOWER BUSHING A (#30530515) |
| 23 | 30530534 | DUST COVER EACH (#30530534) |
| 24 | 30530531 | WASHER (#30530531) |
| 25 | 30530532 | CIRCLIP (#30530532) |
| 26 | 30530502 | FORK SEAL MARZOCCHI (#30530502) |
| 27 | 37530506 | SPACER (#37530506) |
| 28 | 30530520 | UPPER BUSHING (#30530520) |
| 29 | 30522630 | LH sleeve (#30522630) |
| 30 | 30530521 | DRAIN SCREW A (#30530521) |
| 31 | 30530530 | STUD (#30530530) |
| 32 | 27530521 | WASHER (#27530521) |
| 33 | 27530520 | NUT NYLOCK (#27530520) |
| 34 | 30526630 | #34 Spring (#30526630) |
| 35 | 30522530 | RH sleeve (#30522530) |
| 36 | 30530539 | Top hose clamp (#30530539) |
| 37 | 30530538 | Bottom hose clamp (#30530538) |
| 38 | 30530540 | Ring (#30530540) |
| 39 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 40 | 14516700 | SHIM (#14516700) |
| 41 | 14517000 | RING DUST SEAL (#14517000) |
| 42 | 30490230 | Front fork (#30490230) |
