1992 1997 Quota 1000 Front Rear Mudguards
| Position | Part Number | Description |
|---|---|---|
| 1 | 304344301 | Front mudguard (#304344301) |
| 1 | 30434431 | Front mudguard (#30434431) |
| 1 | 30434432 | Front mudguard (#30434432) |
| 1 | 30434433 | Front mudguard (#30434433) |
| 1 | 89000058 | Front mudguard (#89000058) |
| 2 | 30436630 | U-BOLT (#30436630) |
| 3 | 98054320 | BOLT (#98054320) |
| 4 | 95000206 | WASHER (#95000206) |
| 5 | 30437030 | Rear mudguard (#30437030) |
| 6 | 98230616 | SCREW (#98230616) |
| 7 | 30438530 | REAR MUDGUARD SUPPORT (#30438530) |
| 8 | 98612320 | ALLEN BOLT (#98612320) |
| 9 | 61013800 | SPRING WASHER (#61013800) |
| 10 | 30438930 | Shock absorber cover (30438930) Quota (#30438930) |
| 11 | 30439330 | PLATE (#30439330) |
| 12 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 13 | 95100118 | WASHER (#95100118) |
| 14 | 92630106 | NUT USE 92630707 (#92630106) |
| 15 | 30414330 | Protection (#30414330) |
| 16 | 95004206 | WASHER (#95004206) |
| 17 | 30479630 | Toolbox (#30479630) |
| 18 | 29728960 | STRAP (#29728960) |
| 19 | 30437430 | PLATE A (#30437430) |
| 20 | 98622214 | SCREW (#98622214) |
| 21 | 31745860 | REFLEX REFLECTOR (#31745860) |
| 22 | 98250516 | SCREW (#98250516) |
| 23 | 92630105 | NUT (#92630105) |
| 24 | 91551062 | GROMMET (#91551062) |
| 25 | 30468230 | PLATE (#30468230) |
| 26 | 92660601 | CAGE NUT (#92660601) |
| 27 | 29577860 | PLASTIC WASHER (#29577860) |
| 28 | 98230612 | ALLEN SCREW (#98230612) |
| 29 | 93180216 | RUBBER PLUG (#93180216) |
| 30 | 30926132 | Decal Quota 1000 inch (#30926132) |
| 31 | 30474630 | REAR MUD GUARD (#30474630) |
| 32 | 39474600 | NUMBER PLATE HOLDER (#39474600) |
| 33 | 98054216 | SCREW (#98054216) |
| 34 | 92602206 | NUT (#92602206) USE STHN6MM |
