| Position |
Part Number |
Description |
| 1 |
191002051
|
FUEL TANK BLANK (#191002051) |
| 1 |
23100290
|
Fuel tank (#23100290) |
| 1 |
23100290003
|
Fuel tank,white w/black decals (#23100290003) |
| 1 |
23100290004
|
Fuel tank,white w/blue dec. (#23100290004) |
| 1 |
89000136
|
Fuel tank, navy blue (#89000136) |
| 1 |
89000257
|
Fuel tank, sky blue (#89000257) |
| 2 |
28103945
|
GAS CAP (#28103945) USE 28103946 |
| 3 |
141040551
|
SIDE HEAD COVER (#141040551) |
| 3 |
23104090
|
TANK LID WHITE (#23104090) |
| 3 |
89000137
|
Cover, navy blue (#89000137) |
| 3 |
89000290
|
Cover, sky blue (#89000290) |
| 4 |
14736856
|
LOCK W/ KEY (#14736856) |
| 5 |
18105001
|
LATCH (#18105001) |
| 6 |
19104950
|
RETAINER (#19104950) |
| 7 |
19104336
|
GROMMET (#19104336) |
| 8 |
98054210
|
BOLT (#98054210) |
| 9 |
95129100
|
WASHER (#95129100) |
| 10 |
28917300
|
BADGE (#28917300) |
| 12 |
23105470
|
PETCOCK RH A (#23105470) |
| 13 |
23105370
|
LH PETCOCK (#23105370) |
| 14 |
19102750
|
STRAP (#19102750) |
| 15 |
194762501
|
RH body panel blank (#194762501) |
| 15 |
23476290
|
RH side panel, white (#23476290) |
| 15 |
23476290003
|
RH side panel,wh.w/ black dec. (#23476290003) |
| 15 |
23476290004
|
RH side panel, wh.w/blue decal (#23476290004) |
| 15 |
89000140
|
RH side panel, navy blue (#89000140) |
| 15 |
89000258
|
RH side panel, sky blue (#89000258) |
| 16 |
194763501
|
LH body panel blank (#194763501) |
| 16 |
23476390
|
LH side panel, white (#23476390) |
| 16 |
23476390003
|
LH side panel,wh.w/ black dec. (#23476390003) |
| 16 |
23476390004
|
LH side panel, wh.w/blue decal (#23476390004) |
| 16 |
89000141
|
LH side panel, navy blue (#89000141) |
| 16 |
89000259
|
LH side panel, sky blue (#89000259) |
| 17 |
19478150
|
RH COVER GRILL (#19478150) |
| 18 |
19478250
|
LH COVER GRILL (#19478250) |
| 19 |
19478550
|
RUBBER GROMMET LOWER FOR SIDE COVER V35-V50 (#19478550) |
| 20 |
19478750
|
GROMMET-SIDE COVER RUBBER UPPER V35-V50 (#19478750) |
| 21 |
19922051
|
V50 BADGE (#19922051) |
| 22 |
39922200
|
PLATE (#39922200) |
| 23 |
23460590
|
Saddle (#23460590) |
| 24 |
28460945
|
#30 Tab (#28460945) |
| 25 |
28461345
|
#31 Rear saddle hinge (#28461345) |
| 26 |
28461300
|
FT SEAT HINGE A (#28461300) |
| 27 |
98054316
|
BOLT (#98054316) USE STHB6X16 |
| 28 |
95100139
|
WASHERS (#95100139) |
| 29 |
95021106
|
WASHER, WAVE (#95021106) |
| 30 |
23472690
|
Rear fairing, white s.za decalco (#23472690) |
| 30 |
23472690003
|
Rear fairing, wh.w/ Black dec. (#23472690003) |
| 30 |
23472690004
|
Rear fairing,wh.w/ Blue Dec. (#23472690004) |
| 30 |
234726901
|
Rear fairing, blank (#234726901) |
| 30 |
89000129
|
Rear fairing, navy blue (#89000129) |
| 30 |
89000289
|
Rear fairing, sky blue (#89000289) |
| 31 |
28923400
|
BADGE (#28923400) |
| 32 |
28439845
|
#26 RH gasket (#28439845) |
| 33 |
28439846
|
#25 LH gasket (#28439846) |
| 34 |
28479945
|
#40 Rubber spacer (#28479945) |
| 35 |
28472545
|
#33 Fixing pin (#28472545) |
| 36 |
98280616
|
SCREW (#98280616) |
| 37 |
95000206
|
WASHER (#95000206) |
| 38 |
28464401
|
Pillion grab bar (#28464401) |
| 39 |
28478645
|
#18 Washer (#28478645) |
| 40 |
28471845
|
#19 Spacer (#28471845) |
| 41 |
28471945
|
#20 Pin (#28471945) |
| 42 |
23466890
|
Pin (#23466890) |
| 43 |
95129180
|
WAVE WASHER (#95129180) |
| 45 |
00823956080
|
OIL BREATHER HOSE (#00823956080) |
| 46 |
28157950
|
BREATHER PIPE CLAMP (#28157950) |
| 47 |
23736891
|
Lock kit BOSCH (#23736891) |
| 48 |
23923390003
|
Decal set, black (#23923390003) |
| 48 |
23923390004
|
Decal set, blue (#23923390004) |
| 49 |
37105305
|
PETCOCK ELECTRIC SOLINOID VALVE (#37105305) |
| 50 |
90706220
|
O RING (#90706220) |
| 51 |
31105481
|
Fuel level sensor (#31105481) |
| 52 |
27738622
|
Adapter wiring (#27738622) |
