1993 1994 Strada 1000 Crankcase
| Position | Part Number | Description |
|---|---|---|
| 1 | 14000765 | CRANKCASE USE 29000750 (#14000765) |
| 1 | 29000740 | CRANKCASE BARE C (#29000740) |
| 2 | 12003900 | PLUG CAP (#12003900) |
| 3 | 96508066 | SHORT STUD (#96508066) |
| 4 | 96508075 | LONG STUD (#96508075) |
| 5 | 95004208 | WASHER (#95004208) |
| 6 | 92602208 | NUT (#92602208) |
| 7 | 12018900 | BUSH (#12018900) |
| 8 | 95512081 | PIN (#95512081) |
| 9 | 14011900 | Front Main Bearing (#14011900) |
| 9 | 14011901 | Front Main Bearing 1ST U/S (#14011901) |
| 10 | 12012200 | PIN (#12012200) |
| 11 | 98054425 | BOLT (#98054425) |
| 12 | 61270300 | WASHER (#61270300) |
| 13 | 18001150 | COVER SPACER (#18001150) |
| 14 | 98310630 | SCREW (#98310630) |
| 15 | 14001400 | TIMING COVER USE 2900 1450 (#14001400) |
| 16 | 12001200 | TIMING COVER GASKET (#12001200) USE 05001231 |
| 17 | 90402840 | SEAL (#90402840) |
| 18 | 98622325 | BOLT CHROME (#98622325) |
| 19 | 98620335 | SCREWS (#98620335) |
| 20 | 18001650 | ALTERNATOR COVER PLASTIC (#18001650) |
| 21 | 14003600 | PAN GASKET (#14003600) |
| 22 | 14003501 | OIL SUMP 03003501 (#14003501) |
| 23 | 14003800 | FILLER CARTRIDG (#14003800) |
| 24 | 12003702 | DRAIN PLUG MAGNETIC (#12003702) |
| 25 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 26 | 98052390 | BOLT (#98052390) |
| 27 | 95004206 | WASHER (#95004206) |
| 28 | 30004910 | DIPSTICK (#30004910) |
| 29 | 12011800 | REAR MAIN FLANGE BEARING GASKET (#12011800) |
| 30 | 12011400 | Rear Main Bearing (#12011400) |
| 30 | 12011401 | Rear Main Bearing U/S 2MM (#12011401) |
| 30 | 12011402 | Rear Main Bearing (#12011402) |
| 30 | 12011403 | Rear Main Bearing (#12011403) |
| 31 | 12011700 | PIN (#12011700) |
| 32 | 90405367 | CRANKSHAFT SEAL - REAR MAIN (#90405367) |
| 33 | 29999000 | CAL II GSKT.SET (#29999000) |
| 34 | 17999550 | SEAL KIT ENGINE (#17999550) |
| 35 | 98620355 | BOLT (#98620355) |
| 36 | 14003240 | FLANGE (#14003240) |
| 37 | 90706178 | O RING (#90706178) |
| 38 | 29018360 | DIST PLUG A (#29018360) |
| 39 | 90706313 | O RING (#90706313) |
| 40 | 98250820 | SCREW (#98250820) |
| 41 | 30991014 | ENGINE ASSY C (#30991014) |
| 41 | 30991080 | Engine cpl. (#30991080) |
