1993 1994 Strada 1000 Front Mudguard Rear Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 304344101 | #01 Front mud'ard (#304344101) |
| 1 | 30434412 | FRT FENDER GREE B (#30434412) |
| 1 | 30434481 | FRONT FENDER GO B (#30434481) |
| 1 | 30434482 | FRONT FENDER BL B (#30434482) |
| 1 | 30434483 | FRONT FENDER RE B (#30434483) |
| 2 | 98230816 | SCREW (#98230816) |
| 3 | 61270300 | WASHER (#61270300) |
| 4 | 28436747 | PLATE (#28436747) |
| 5 | 14438700 | SPLASH GUARD (#14438700) |
| 6 | 93180080 | PLUG (#93180080) |
| 7 | 98054320 | BOLT (#98054320) |
| 8 | 95100141 | WASHER (#95100141) |
| 9 | 93301313 | BRACKET (#93301313) |
| 10 | 93110060 | RUBBER WASHER (#93110060) |
| 11 | 92630106 | NUT USE 92630707 (#92630106) |
| 12 | 95004206 | WASHER (#95004206) |
| 13 | 98054325 | BOLT (#98054325) |
| 14 | 30437110 | REAR FENDER A (#30437110) |
| 15 | 93110135 | GROMMET A (#93110135) |
| 16 | 28912740 | SHOCK ADJ TOOL (#28912740) |
| 17 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 18 | 30900010 | O MANL ITALIAN A (#30900010) |
| 18 | 30900011 | O MANL SPIII (#30900011) |
| 18 | 30900012 | O MANL FRENCH NLA (#30900012) |
| 18 | 30900013 | O MANL GERMAN A (#30900013) |
| 19 | 30900080 | O MANL STRADA ENGLISH, ITALIAN, FRENCH, GERMAN (#30900080) |
| 20 | 28475233 | MOUNT A (#28475233) |
| 21 | 91862408 | RIVET (#91862408) |
| 22 | 28745800 | REAR REFLECTOR (#28745800) |
| 23 | 95129080 | WASHER (#95129080) |
| 24 | 92602204 | NUT (#92602204) |
