1993 1997 Nevada 750 Transmission Cage
| Position | Part Number | Description |
|---|---|---|
| 1 | 31200880 | #01 Gearbox cover, grey (#31200880) |
| 2 | 92204215 | BEARING (#92204215) |
| 3 | 90402841 | RING (#90402841) USE 886364 |
| 4 | 90706140 | O RING (#90706140) |
| 5 | 23213870 | PLATE A (#23213870) |
| 5 | 23213872 | #05 Plate (#23213872) |
| 6 | 98622314 | ALLEN BOLT (#98622314) |
| 7 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 8 | 19235800 | PLATE (#19235800) |
| 10 | 23200370 | Gasket (#23200370) USE 887005 |
| 11 | 19207220 | SWITCH, NEUTRAL (#19207220) |
| 12 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 13 | 19237800 | BOLT, CONCENTRIC (#19237800) |
| 14 | 92602512 | NUT (#92602512) |
| 15 | 19201120 | GASKET (#19201120) |
| 16 | 19002020 | BUSH (#19002020) |
| 17 | 31200280 | #17 Gearbox, grey (#31200280) |
| 18 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 18 | 98620335 | SCREWS (#98620335) |
| 19 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 20 | 55234700 | PAWL (#55234700) |
| 21 | 94321067 | SPRING (#94321067) |
| 22 | 19206501 | VENT PLUG (#19206501) |
| 23 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 24 | 19351200 | OIL FILLER CAP (#19351200) |
| 25 | 90706203 | O RING (#90706203) |
| 26 | 31003766 | DRAIN PLUG (#31003766) |
| 27 | 19208220 | SHIELD (#19208220) |
| 27 | 23208272 | #27 Oil bulhead (#23208272) |
| 28 | 92201120 | BEARING (#92201120) |
| 29 | 19202320 | Bushing (#19202320) |
| 30 | 27991560 | GEARBOX C (#27991560) |
| 30 | 27991561 | #29 Transmission assy and housing (#27991561) |
