1993 Sp III 1000 Handlebar Controls
| Position | Part Number | Description |
|---|---|---|
| 1 | 30600310 | HANDLEBAR 1000SP III (#30600310) |
| 2 | 27603400 | THROTTLE/SWITCH ASS. NLA 7/05 (#27603400) |
| 3 | 27738815 | STARTER SWITCH (27738815) (#27738815) |
| 4 | 27604415 | GUIDE BLOCK (#27604415) |
| 5 | 27603815 | THROTTLE TUBE (#27603815) |
| 6 | 27604515 | CBLE GUIDE (#27604515) |
| 7 | 27603620 | RING (#27603620) |
| 8 | 27603520 | GRIP RH (#27603520) |
| 9 | 28117578 | THROTTLE CABLE (#28117578) |
| 10 | 28117478 | CABLE SPLITTER (#28117478) |
| 11 | 28607678 | ADJUSTER ASSY (#28607678) |
| 12 | 30117710 | CABLE THROTTLE SP3 LONG DOMINO THROTTLE (#30117710) |
| 13 | 27605515 | CL PERCH USE 30605530 (#27605515) |
| 14 | 27605715 | CLUTCH LEVER (#27605715) |
| 15 | 27601215 | ALLEN BOLT BLACK (#27601215) |
| 16 | 27601015 | HALF CLAMP (#27601015) |
| 17 | 27601815 | LEVER SUPPORT (#27601815) |
| 18 | 27602515 | ADJUSTER (#27602515) |
| 18 | 30602500 | ADJUSTER ASSY (#30602500)USE AP8118348 |
| 19 | 27659415 | CHOKE LEVER ASSY (#27659415) |
| 20 | 30093010 | CLUTCH CABLE (#30093010) |
| 20 | 30093011 | CLUTCH CABLE STRADA 1000 2ND SERIES (#30093011) |
| 21 | 27663815 | CABLE BOOT (#27663815) |
| 22 | 30132810 | 1000 SP III CHOKE CABLE (#30132810) |
| 23 | 30607910 | CABLE SPLITTER (#30607910) |
| 24 | 30574710 | H/BAR SHROUD A (#30574710) |
| 25 | 30769510 | EMBLEM-EAGLE A (#30769510) |
| 26 | 98230612 | ALLEN SCREW (#98230612) |
| 27 | 29577860 | PLASTIC WASHER (#29577860) |
| 28 | 29573860 | GROMMET (#29573860) |
| 29 | 12717600 | Cap (#12717600) |
| 30 | 29133550 | CABLE CHOKE RH (#29133550) |
| 31 | 29134050 | CABLE-CHOKE LH (#29134050) |
| 32 | 27738015 | SWITCH (#27738015) |
| 33 | 27603120 | WASHER (#27603120) |
| 34 | 27603020 | GRIP LH (#27603020) |
| 35 | 29602760 | BAR END STABILIZER (#29602760) |
| 36 | 93180080 | PLUG (#93180080) |
| 37 | 29606970 | WASHER (PAIR) (#29606970) |
