1994 1995 850 T5 Police 850 Carburetors
| Position | Part Number | Description |
|---|---|---|
| 1 | 28937511 | SLIDE 50/3 A (#28937511) |
| 2 | 28937711 | SLIDE NEEDLE K23 (#28937711) |
| 3 | 28935511 | ATOMIZER #AB264 (#28935511) |
| 4 | 28935711 | JET (#28935711) USE 6413130 |
| 5 | 66935910 | PILOT JET (#66935910) USE 148650 |
| 6 | 17936067 | STARTER JET #75 (#17936067) |
| 7 | 28939011 | PUMP JET #38 (#28939011) |
| 8 | 17939167 | Needle valve 250 (#17939167) |
| 9 | 14933000 | FLOATS - ALL BIG BLOCK (#14933000) |
| 10 | 49938900 | PIPE (#49938900) |
| 11 | 19938880 | NUT (#19938880) |
| 12 | 53937200 | ADJUSTER (#53937200) |
| 14 | 14938050 | SPRING (#14938050) |
| 16 | 14934650 | SCREW (#14934650) |
| 19 | 17937167 | THR SPRING (#17937167) |
| 24 | 12937200 | CABLE ADJUSTER (#12937200) |
| 25 | 12937300 | NUT (#12937300) |
| 26 | 13937900 | SCREW (#13937900) |
| 27 | ||
| 29 | 13937600 | SPRING (#13937600) |
| 30 | 13937800 | VALVE CHOKE (#13937800) |
| 32 | 65933700 | WASHER (#65933700) |
| 33 | 13936300 | SPRING (#13936300) |
| 34 | 30936210 | MIXTURE SCREW (#30936210) |
| 36 | 14931650 | WASHER A (#14931650) |
| 37 | 13936700 | SPRING (#13936700) |
| 38 | 13936600 | SCREW (#13936600) |
| 43 | 14931050 | DIAPHRAGM (#14931050) |
| 44 | 14936950 | SPRING (#14936950) |
| 48 | 14936550 | SCREW (#14936550) |
| 49 | 14936450 | NUT (#14936450) |
| 51 | 13932900 | WASHER (#13932900) |
| 52 | 14931350 | VALVE (#14931350) |
| 54 | 43934000 | Fuel Filter Screen (43934000) (#43934000) |
| 55 | 13934600 | CARB.ADAPTER BLACK PLASTIC (#13934600) |
| 56 | 10934900 | BOLT (#10934900) |
| 59 | 13933100 | FLOAT PIN (13933100) (#13933100) |
| 63 | 28939911 | CARB GASKET KIT (#28939911) |
| 64 | 14115550 | GASKET (#14115550) |
| 65 | 29115020 | MANIFOLD (#29115020) |
| 66 | 98622325 | BOLT CHROME (#98622325) |
| 67 | 14114350 | CARB MANIFOLD SLEEVE EA. (#14114350) |
| 68 | 93305057 | CLAMP (#93305057) |
| 69 | 00823946060 | Breather pipe (#00823946060) |
| 70 | 98310610 | SCREW (#98310610) |
| 71 | 95100116 | WASHER (#95100116) |
| 72 | 95004206 | WASHER (#95004206) |
| 73 | 28112610 | #73 Carburettor RH (#28112610) |
| 74 | 28112611 | #74 Carburettor LH (#28112611) |
