1994 1996 Sport Carburated 1100 Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 37410205 | FRAME REAR C (#37410205) |
| 2 | 37573106 | SEAT COWL RED C (#37573106) |
| 2 | 37573107 | SEAT COWL BLACK C (#37573107) |
| 2 | 37573108 | SEAT COWL SILVE C (#37573108) |
| 2 | 37573111 | SEAT COWLING - SILVER (#37573111) |
| 2 | 37573112 | SEAT COWL BLUE C SPORT 1100 inch (#37573112) |
| 3 | 37923405 | DECAL SPT 1100 A (#37923405) |
| 3 | 37923406 | DECAL SPT 1100 A (#37923406) |
| 4 | 30942300 | DECAL MOTO GUZZ A (#30942300) |
| 4 | 30942301 | DECAL M-G A (#30942301) |
| 5 | 98230622 | ALLEN SCREW (#98230622) |
| 6 | 30576100 | BUSHING (#30576100) |
| 7 | 91551010 | GROMMET (#91551010) |
| 8 | 37406205 | FRAME STRUT (#37406205) |
| 9 | 37409005 | STUD A (#37409005) |
| 10 | 98054525 | BOLT (#98054525) |
| 11 | 95004210 | WASHER (#95004210) |
| 12 | 92660210 | NUT (#92660210) |
| 13 | 66466815 | HELMET LOCK (#66466815) |
| 14 | 66468115 | SECURITY BOLT (#66468115) |
| 15 | 98251070 | ALLEN SCREW (#98251070) |
| 16 | 30943400 | HOLE PLUG (#30943400) |
| 17 | 92630110 | NUT (#92630110) |
| 18 | 37479605 | TOOL TRAY A (#37479605) |
| 19 | 98054318 | BOLT (#98054318) |
| 20 | 95100141 | WASHER (#95100141) |
| 21 | 92630106 | NUT USE 92630707 (#92630106) |
| 22 | 37437005 | FENDER REAR (#37437005) |
| 24 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 25 | ||
| 26 | 91180608 | SPACER (#91180608) |
| 27 | 91551062 | GROMMET (#91551062) |
| 28 | 30438102 | FLAP SUPPORT A (#30438102) |
| 29 | 30438032 | MUD FLAP REAR A (#30438032) |
| 30 | 98230520 | SCREW (#98230520) USE 840548 |
| 31 | 95007205 | WASHER (#95007205) |
| 32 | 92630205 | LOCK NUT (#92630205) |
| 33 | 23922210 | FASTENER (#23922210) |
| 34 | 95100123 | WASHER (#95100123) |
| 35 | 37909905 | TOOL KIT A (#37909905) |
| 36 | 37900005 | O MANL 1100 SPORT CARB ENGLISH/GERMAN/ & 2 OTHER (#37900005) |
| 37 | 37923305 | DECAL SET GOLD (#37923305) |
| 37 | 37923306 | DECAL SET GLD/R A (#37923306) |
| 39 | 30437430 | PLATE A (#30437430) |
| 40 | 95000205 | WASHER (#95000205) |
| 41 | 30922035 | DECAL CATALYST A (#30922035) |
| 42 | 28438060 | MUD FLAP REAR (#28438060) |
| 43 | 98230620 | ALLEN BOLT (#98230620) |
| 44 | 95001206 | WASHER (#95001206) |
| 45 | 92630207 | NUT NYLOC \ (#92630207) |
