1994 1997 California 1100 Carburetor
| Position | Part Number | Description |
|---|---|---|
| 1 | 30937510 | SLIDE 60/3 A (#30937510) |
| 1 | 30937512 | CARB SLIDE 50/3 (#30937512) |
| 2 | 17937767 | SLIDE NEEDLE K27 (#17937767) |
| 2 | 28937750 | SLIDE NEEDLE K18 (#28937750) |
| 3 | 29935522 | ATOMIZER #AR266 (#29935522) |
| 3 | 30935510 | ATOMIZER #AR268 (#30935510) |
| 3 | 30935565 | ATOMIZER #AB262 (#30935565) |
| 4 | 28935711 | JET (#28935711) USE 6413130 |
| 4 | 28935740 | MAIN JET #125 (#28935740) USE 6413125 |
| 5 | 35935970 | JET (#35935970) USE 148648 |
| 5 | 66935910 | PILOT JET (#66935910) USE 148650 |
| 6 | 14936050 | STARTING JET #70 (#14936050) |
| 7 | 28939050 | JET #33 (#28939050) |
| 8 | 30939110 | FLOAT VALVE (#30939110) |
| 9 | 14933000 | FLOATS - ALL BIG BLOCK (#14933000) |
| 10 | 49938900 | PIPE (#49938900) |
| 11 | 19938880 | NUT (#19938880) |
| 12 | 53937200 | ADJUSTER (#53937200) |
| 14 | 14938050 | SPRING (#14938050) |
| 16 | 14934650 | SCREW (#14934650) |
| 26 | 13937900 | SCREW (#13937900) |
| 27 | ||
| 29 | 13937600 | SPRING (#13937600) |
| 30 | 13937800 | VALVE CHOKE (#13937800) |
| 32 | 65933700 | WASHER (#65933700) |
| 33 | 13936300 | SPRING (#13936300) |
| 34 | 30936210 | MIXTURE SCREW (#30936210) |
| 36 | 14931650 | WASHER A (#14931650) |
| 37 | 13936700 | SPRING (#13936700) |
| 38 | 13936600 | SCREW (#13936600) |
| 43 | 14931050 | DIAPHRAGM (#14931050) |
| 44 | 14936950 | SPRING (#14936950) |
| 46 | 14936850 | COVER (#14936850) |
| 48 | 14936550 | SCREW (#14936550) |
| 49 | 14936450 | NUT (#14936450) |
| 51 | 13932900 | WASHER (#13932900) |
| 52 | 14931350 | VALVE (#14931350) |
| 54 | 43934000 | Fuel Filter Screen (43934000) (#43934000) |
| 55 | 13934600 | CARB.ADAPTER BLACK PLASTIC (#13934600) |
| 56 | 10934900 | BOLT (#10934900) |
| 59 | 13933100 | FLOAT PIN (13933100) (#13933100) |
| 63 | 28939911 | CARB GASKET KIT (#28939911) |
| 64 | 29119306 | CAP-CARB ADJ (#29119306) |
