1994 1997 California 1100 Crank Case
| Position | Part Number | Description |
|---|---|---|
| 1 | 30000760 | CRANKCASE(CARB C (#30000760) |
| 1 | 30000770 | CRANKCASE FI C (#30000770) |
| 2 | 12003900 | PLUG CAP (#12003900) |
| 3 | 96508066 | SHORT STUD (#96508066) |
| 4 | 96508075 | LONG STUD (#96508075) |
| 5 | ||
| 6 | 92602208 | NUT (#92602208) |
| 7 | 12018900 | BUSH (#12018900) |
| 8 | 95512081 | PIN (#95512081) |
| 9 | 14011900 | Front Main Bearing (#14011900) |
| 9 | 14011901 | Front Main Bearing 1ST U/S (#14011901) |
| 10 | 12012200 | PIN (#12012200) |
| 11 | 98054425 | BOLT (#98054425) |
| 12 | 61270300 | WASHER (#61270300) |
| 13 | 18001150 | COVER SPACER (#18001150) |
| 14 | 98310630 | SCREW (#98310630) |
| 15 | 30001460 | TIMING COVER B (#30001460) |
| 16 | 12001200 | TIMING COVER GASKET (#12001200) USE 05001231 |
| 17 | 90402840 | SEAL (#90402840) |
| 18 | 98622325 | BOLT CHROME (#98622325) |
| 19 | 98620335 | SCREWS (#98620335) |
| 20 | 03001600 | 1100EV ALTERNATOR COVER(#03001600) |
| 20 | 18001650 | ALTERNATOR COVER PLASTIC (#18001650) |
| 21 | 14003600 | PAN GASKET (#14003600) |
| 22 | 30003560 | OIL SUMP PAN B (#30003560) |
| 23 | 30003800 | FITTING (#30003800) |
| 24 | 12003702 | DRAIN PLUG MAGNETIC (#12003702) |
| 25 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 26 | 98052390 | BOLT (#98052390) |
| 27 | 95004206 | WASHER (#95004206) |
| 28 | 30004910 | DIPSTICK (#30004910) |
| 29 | 12011800 | REAR MAIN FLANGE BEARING GASKET (#12011800) |
| 30 | 12011400 | Rear Main Bearing (#12011400) |
| 30 | 12011401 | Rear Main Bearing U/S 2MM (#12011401) |
| 30 | 12011402 | Rear Main Bearing (#12011402) |
| 30 | 12011403 | Rear Main Bearing (#12011403) |
| 31 | 12011700 | PIN (#12011700) |
| 32 | 90405367 | CRANKSHAFT SEAL - REAR MAIN (#90405367) |
| 33 | 29999000 | CAL II GSKT.SET (#29999000) |
| 33 | 30999060 | GASKET SET A (#30999060) |
| 34 | 17999550 | SEAL KIT ENGINE (#17999550) |
| 35 | 98620360 | BOLT (#98620360) |
| 36 | 30003260 | SUMP SPACER B (#30003260) |
| 37 | 90706178 | O RING (#90706178) |
| 38 | 29018361 | COVER (#29018361) |
| 39 | 90706313 | O RING (#90706313) |
| 40 | 98250820 | SCREW (#98250820) |
| 41 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 42 | 95100304 | WASHER (#95100304) |
| 43 | 30003770 | MAGNETIC PLUG (#30003770) |
| 44 | 30991060 | MOTOR ASSY CARB C (#30991060) |
| 44 | 30991085 | Engine w/o gearbox 1000 cc (#30991085) |
| 45 | 30991070 | MOTOR ASSY FI C (#30991070) |
| 45 | 30991090 | Engine w/o gearbox 1000 cc (#30991090) |
