1994 1997 California 1100 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | 301002601 | Fuel tank (#301002601) |
| 1 | 30100261 | FUEL-TANK BLACK (#30100261) |
| 1 | 30100262 | FUEL-TANK BLK/GR 30100262 (#30100262) |
| 1 | 30100263 | FUEL-TANK BLK/RED 30100263 (#30100263) |
| 1 | 30100264 | GAS TANK BLK/YE C (#30100264) |
| 1 | 301002651 | Fuel tank (#301002651) |
| 1 | 30100266 | Fuel tank (#30100266) |
| 1 | 30100267 | Fuel tank (#30100267) |
| 1 | 30100268 | Fuel tank (#30100268) |
| 1 | 30100269 | Fuel tank, blue/gold (#30100269) |
| 1 | 30100274 | Fuel tank (#30100274) |
| 1 | 30100278 | GAS TANK BLK/SI C (#30100278) |
| 1 | 30100280 | Fuel tank (#30100280) |
| 1 | ||
| 1 | 30100287 | GAS TANK GRN/BL D (#30100287) |
| 1 | 30100292 | Fuel tank (#30100292) |
| 1 | 30100293 | Fuel tank (#30100293) |
| 1 | 30100294 | Fuel tank (#30100294) |
| 1 | 30100295 | Fuel tank (#30100295) |
| 1 | ||
| 1 | 89000081 | GAS TANK BLK/RE D (#89000081) |
| 1 | 89000103 | GAS TANK BLACK D (#89000103) |
| 1 | 89000119 | USE 89000165 (#89000119) |
| 1 | 89000164 | Fuel tank (#89000164) |
| 2 | 30103960 | GAS CAP (#30103960) |
| 3 | ||
| 4 | 23105470 | PETCOCK RH A (#23105470) |
| 5 | 28108410 | HOSE CLAMP (#28108410) |
| 6 | 29106500 | FUEL PIPE (#29106500) USE 29106551 |
| 7 | 30103060 | FUEL SENSOR OR GAS LEVEL SENDER (#30103060) |
| 8 | 98230830 | BOLT (#98230830) |
| 9 | 95100239 | WASHER (#95100239) |
| 10 | 91551131 | GROMMET (#91551131) |
| 11 | 92660801 | CAGE NUT (#92660801) |
| 12 | 30472460 | SHROUD RH (#30472460) |
| 13 | 30472960 | SHROUD LH A (#30472960) |
| 14 | 93110082 | RUBBER WASHER (#93110082) |
| 15 | 98230816 | SCREW (#98230816) |
| 16 | 95001208 | WASHER (#95001208) |
| 17 | 98230612 | ALLEN SCREW (#98230612) |
| 18 | 95001206 | WASHER (#95001206) |
| 19 | 29995735 | DECAL UNLEADED A (#29995735) |
| 20 | 28105280 | CAP (#28105280) |
| 21 | 25656102 | GASKET (#25656102) |
| 22 | 28462645 | SPACER (#28462645) |
| 23 | 30736860 | LOCK SET COMPLETE (#30736860) |
| 24 | 19917835 | DECAL EAGEL (#19917835) |
| 24 | 29917853 | Tank Decals (#29917853) |
| 24 | 30917860 | DECAL M-G RH A (#30917860) |
| 24 | 30917960 | DECAL M-G LH A (#30917960) |
