1994 1997 California 1100 Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 30630660 | REAR WHEEL ASSY C (#30630660) |
| 2 | 30631160 | SPOKE SHORT (#30631160) |
| 3 | 30631430 | SPOKE, LONG (#30631430) |
| 4 | 27611710 | SPOKE NIPPLE (#27611710) |
| 5 | 12616101 | BALANCE WEIGHT (#12616101) |
| 5 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 5 | 12616103 | BALANCE WEIGHT (#12616103) |
| 6 | 30632460 | DISC SPACER A (#30632460) |
| 7 | 92204220 | BEARING (#92204220) |
| 8 | 90272047 | CIRCLIP (#90272047) |
| 9 | 30635860 | BRAKE DISC B (#30635860) |
| 10 | 30613760 | INNER DISC A (#30613760) |
| 11 | 28613560 | BRAKE BUSHING (#28613560) |
| 12 | 28618860 | CUP SPRING (#28618860) |
| 13 | 90271022 | CIRCLIP A (#90271022) |
| 14 | 30611460 | ALLEN BOLT (#30611460) |
| 15 | 30633360 | AXLE REAR A (#30633360) |
| 16 | 98622430 | SCREW (#98622430) |
| 17 | 14615901 | WASHER (#14615901) |
| 19 | 17633550 | CUP (#17633550) |
| 20 | 01336800 | RUBBER BLOCK (#01336800) |
| 21 | 90706490 | O RING (#90706490) |
| 22 | 30335260 | DISC-CUSH DRIVE B (#30335260) |
| 23 | 14335303 | RING (#14335303) |
| 24 | 17335950 | LOCK PLATE (#17335950) |
| 25 | 61013800 | SPRING WASHER (#61013800) |
| 26 | 98054312 | BOLT (#98054312) |
| 27 | 30634160 | SPACER A (#30634160) |
| 28 | 14634400 | RING (#14634400) |
| 29 | 29616450 | NUT A (#29616450) |
| 30 | 30630760 | WHEEL RIM REAR C (#30630760) |
