1994 1997 California 1100 Rh Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 30660160 | MASTER CYLINDER ASSY (#30660160) |
| 2 | 30605680 | BREMBO BRAKE LEVER A (#30605680) |
| 3 | 27664075 | HALF CLAMP (#27664075) |
| 4 | 39663801 | DUST CAP (#39663801) |
| 5 | 27604815 | LEVER PIN (#27604815) |
| 6 | 27663615 | RUBBER USE BREMBO #110.3530.40 (#27663615) |
| 7 | 30749860 | MICROSWITCH - (#30749860) |
| 8 | 98200214 | SCREW (98200214) (#98200214) |
| 9 | 92295708 | BALL (#92295708) |
| 10 | 27661115 | MASTER CYL LID KIT (#27661115) |
| 11 | 95990028 | SCREW (#95990028) |
| 12 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 13 | 28657140 | FLEX PIPE (#28657140) |
| 14 | 17658460 | CLAMP (#17658460) |
| 15 | 17658260 | RUBBER RING (#17658260) |
| 16 | 28653001 | CALIPER (#28653001) |
| 17 | 17654760 | COVER (#17654760) |
| 18 | 28654601 | (#28654601) |
| 19 | 23943510 | CHROME PLUG (#23943510) |
| 20 | 98622525 | BOLT (#98622525) |
| 21 | 95129180 | WAVE WASHER (#95129180) |
| 22 | 95100332 | SHIM 0.5 MM (#95100332) |
| 22 | 95100333 | SHIM 0.8 MM (#95100333) |
| 23 | 17659260 | BLEEDER SCREW KIT (#17659260) |
| 24 | 14659100 | BRAKE PINS KIT 2 PER BAG (#14659100) |
| 25 | 14659000 | CALIPER KIT (#14659000) |
| 26 | 92601002 | NUT (#92601002) |
