1995 2001 850 T5 Police 850 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 28400149 | FRAME RED A (#28400149) |
| 2 | 93180080 | PLUG (#93180080) |
| 3 | 28463045 | #03 Knob (#28463045) |
| 4 | 28462945 | #04 Bush (#28462945) |
| 5 | 94321119 | #05 Spring (#94321119) |
| 6 | 28462645 | SPACER (#28462645) |
| 7 | 35782880 | SCREW (#35782880) |
| 8 | 90280006 | E CLIP (#90280006) USE 005965 |
| 9 | 17424150 | #09 Coil support plate (#17424150) |
| 10 | 95100121 | WASHER (#95100121) |
| 11 | 92630106 | NUT USE 92630707 (#92630106) |
| 12 | 98622320 | SCREW (#98622320) |
| 13 | 95100141 | WASHER (#95100141) |
| 14 | 93110060 | RUBBER WASHER (#93110060) |
| 15 | 95000206 | WASHER (#95000206) |
| 16 | 98622325 | BOLT CHROME (#98622325) |
| 17 | 98621650 | SCREW (#98621650) |
| 18 | 14103800 | BUSH (#14103800) |
| 19 | ||
| 20 | 17478550 | PIN (#17478550) |
| 21 | 28478548 | #21 RH pin (#28478548) |
| 22 | 14609650 | TIE WRAP (#14609650) |
| 23 | 95021112 | WASHER (#95021112) |
| 24 | 92602312 | NUT (#92602312) |
| 25 | 91180613 | SPACER (#91180613) |
| 26 | 39103500 | PLATE (#39103500) |
| 27 | 98052325 | BOLT (#98052325) |
| 28 | 95004206 | WASHER (#95004206) |
| 30 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 31 | 28109040 | BUFFER (#28109040) |
| 32 | 28463545 | #32 Radio support (#28463545) |
| 33 | 23463690 | #33 Radio support (#23463690) |
| 34 | 28478845 | #34 Release device (#28478845) |
| 35 | 19434000 | SPRING (#19434000) |
| 36 | 14461400 | GRIP (#14461400) |
| 37 | 98054318 | BOLT (#98054318) |
