1996 2001 V 75 PA Nuovo Tipo 750 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 23494070 | #01 Stem base (#23494070) |
| 2 | 18513560 | SHIM (#18513560) |
| 3 | 98072555 | BOLT BLACK (#98072555) |
| 4 | 95007210 | WASHER (#95007210) |
| 5 | 91181016 | SPACER (#91181016) |
| 6 | 18513460 | NUT (#18513460) |
| 7 | 31493140 | #07 Fork upper plate POLIZIA (#31493140) |
| 8 | 98610540 | BOLT (#98610540) |
| 9 | 98612535 | SCREW BLACK (#98612535) |
| 10 | 18516660 | BUSHING (#18516660) |
| 11 | 20522520 | RH sleeve (#20522520) |
| 12 | 20522620 | LH sleeve (#20522620) |
| 13 | 90403857 | FORK SEAL (#90403857) USE 429013 |
| 14 | 20527620 | #14 Bush (#20527620) |
| 15 | 98622320 | SCREW (#98622320) |
| 16 | 95100116 | WASHER (#95100116) |
| 17 | 23525470 | #17 Sleeve (#23525470) |
| 18 | 31524550 | #18 Dust cover (#31524550) |
| 19 | 23526470 | Shock absorber (#23526470) |
| 20 | 23526610 | #20 Return spring (#23526610) |
| 21 | 28527540 | LOWER SHOCK BUSHING (#28527540) |
| 22 | 23526910 | #22 Spring (#23526910) |
| 23 | 98620545 | ALLEN BOLT (#98620545) |
| 24 | 98622530 | BOLT (#98622530) |
| 25 | 28556450 | SCREW (#28556450) |
| 26 | 28556250 | VALVE (#28556250) |
| 27 | 90706282 | O RING (#90706282) |
| 28 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 29 | 19529660 | TUBE (#19529660) |
| 30 | 92602210 | NUT (#92602210) |
| 31 | 27499120 | WASHER A (#27499120) |
| 32 | 90706094 | O RING-VITON (#90706094) |
| 33 | 23526370 | #05 Anti-rubbing pipe (#23526370) |
| 34 | 92602308 | NUT (#92602308) |
| 35 | 23527910 | SPACER (#23527910) |
| 36 | 28526540 | WASHER (#28526540) |
| 37 | 17500200 | CLAMP (#17500200) |
| 38 | 28500745 | #33 Stud bolt (#28500745) |
| 39 | 19500715 | Stud bolt (#19500715) |
| 40 | 95000208 | WASHER (#95000208) |
| 41 | 92630108 | NUT 8MM (#92630108) |
| 42 | 17517700 | DISC 1415 6600 (#17517700) |
