1996 Daytona Racing 1000 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 30494045 | FORK BASE GREY B (#30494045) |
| 2 | 98622430 | SCREW (#98622430) |
| 3 | 30493145 | FORK TOP GREY B (#30493145) |
| 4 | 30513400 | NUT (#30513400) USE 30513401 |
| 5 | 37530508 | SCREW & O RING (#37530508) |
| 6 | 37530509 | ADJ KNOB RH A (#37530509) |
| 6 | 37530510 | ADJ KNOB LH A (#37530510) |
| 7 | 30530505 | WASHER (#30530505) |
| 8 | 30530506 | NUT (#30530506) |
| 9 | 30530507 | FORK PLUG (#30530507) |
| 10 | 30530508 | O RING (#30530508) |
| 11 | 37530511 | DAMPING ADJ (#37530511) |
| 12 | 37530507 | NUT A (#37530507) |
| 13 | 30530523 | SPACER TUBE A (#30530523) |
| 14 | 30530524 | SPRING ROD A (#30530524) |
| 15 | 37530505 | CIRCLIP A (#37530505) |
| 16 | 30530514 | TUBE (#30530514) |
| 17 | 30526600 | FORK SPRING A (#30526600) |
| 18 | 30525400 | FORK TUBE B (#30525400) |
| 19 | 30530515 | LOWER BUSHING A (#30530515) |
| 20 | 37530512 | DAMPER RH B (#37530512) |
| 21 | 30524500 | SEAL (#30524500) |
| 22 | 30530518 | CIRCLIP (#30530518) |
| 23 | 30530502 | FORK SEAL MARZOCCHI (#30530502) |
| 24 | 37530506 | SPACER (#37530506) |
| 25 | 30530520 | UPPER BUSHING (#30530520) |
| 26 | 30522545 | FORK LEG RH GRE B (#30522545) |
| 27 | 98620335 | SCREWS (#98620335) |
| 28 | 37530513 | DAMPER LH B (#37530513) |
| 29 | 30522645 | FORK LEG LH GRE B (#30522645) |
| 30 | 30530521 | DRAIN SCREW A (#30530521) |
| 31 | 39523700 | GASKET A (#39523700) |
| 32 | 66530514 | ALLEN BOLT (#66530514) |
| 33 | 30530527 | FORK OIL/ LITER S (#30530527) |
| 34 | 90706140 | O RING (#90706140) |
