1997 1998 Daytona RS 1000 Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 02432100 | SIDE STAND B (#02432100) |
| 1 | 30432100 | SIDE STAND (#30432100) |
| 2 | 01433400 | SIDE STAND MOUNT B (#01433400) |
| 3 | 30432801 | SCREW (#30432801) |
| 4 | 95021114 | LOCK WASHER (#95021114) |
| 5 | 01433200 | PIVOT PIN (#01433200) |
| 5 | 01433201 | PIVOT PIN (#01433201) |
| 6 | 30432700 | PLATE (#30432700) |
| 7 | 30434001 | SPRING (#30434001) |
| 8 | 95100521 | WASHER (#95100521) |
| 9 | 30434000 | SPRING, SIDE STAND (#30434000) |
| 10 | 01433600 | PLATE A (#01433600) |
| 11 | 93180575 | BUFFER (#93180575) use 19705900 |
| 12 | 30442705 | FOOTREST BRACKET RH (#30442705) |
| 13 | 98251040 | SCREW (#98251040) |
| 14 | 92630110 | NUT (#92630110) |
| 15 | 30440705 | FOOTREST RH FRONT (#30440705) |
| 16 | 30441805 | FOOTREST (#30441805) |
| 17 | 30441005 | FOOTREST PIN (#30441005) |
| 18 | 30441105 | SPRING (#30441105) |
| 19 | 30442205 | FOOTREST PIN A (#30442205) |
| 20 | 90280006 | E CLIP (#90280006) USE 005965 |
| 21 | 01444650 | MUFF BRKT RH B (#01444650) |
| 22 | 01444750 | MUFF BRKT LH B (#01444750) |
| 23 | 30442405 | FOOTREST RH REAR (#30442405) |
| 24 | 30442805 | FOOTREST L/H REAR (#30442805) |
| 25 | 30443105 | STOP PLATE (#30443105) |
| 26 | 94321062 | SPRING (#94321062) |
| 27 | 92295706 | BALL (#92295706) |
| 28 | 30441605 | FOOTREST SHIM (#30441605) |
| 29 | 92660310 | NUT A (#92660310) |
| 30 | 30433800 | TUBE (#30433800) |
| 31 | 02431900 | SIDE STAND LEVER A (#02431900) |
| 32 | 98230615 | ALLEN SCREW A (#98230615) |
| 33 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 34 | 03759100 | SAFETY SWITCH (#03759100) |
| 35 | 02433800 | MOUNT PLATE A (#02433800) |
| 36 | ||
| 37 | 97040220 | ADJUSTER A (#97040220) |
| 38 | 92602205 | NUT (#92602205) |
| 39 | 02736200 | SWITCH HARNESS A (#02736200) |
| 40 | 02979201 | SIDE STAND KIT S (#02979201) |
