1997 1999 V 10 Centauro 1000 Dashboard
| Position | Part Number | Description |
|---|---|---|
| 1 | 02762400 | SPEEDOMETER VEGLIA BRAND WHITE FACE (#02762400) |
| 1 | 2761500 | #01 Speedometer KMH Borletti (#2761500) |
| 2 | 23768310 | ANGLE DRIVE (#23768310) |
| 3 | 02762800 | TRIP RESET KNOB (#02762800) |
| 4 | 01760400 | SPEEDO CABLE (#01760400) |
| 5 | ||
| 6 | 12763300 | SPEEDOMETER DRIVE GEAR (#12763300) |
| 7 | ||
| 8 | 17762150 | SPEEDO LITES USE 93450120 OR 93450119 (#17762150) |
| 9 | 02767200 | TACHOMETER WHITE FACE (#02767200) |
| 10 | 02763400 | STUD (#02763400) |
| 11 | 02763000 | STUD A (#02763000) |
| 12 | 02764000 | BRACKET (#02764000) |
| 13 | 02762300 | RUBBER (#02762300) |
| 14 | 02761900 | TACH HOUSING (#02761900) |
| 15 | 02762000 | SPEEDO HOUSING (#02762000) |
| 16 | 98230510 | ALLEN BOLT (#98230510) |
| 17 | 95129100 | WASHER (#95129100) |
| 18 | 02766000 | GAUGE MOUNT A (#02766000) |
| 19 | 02765500 | PANEL RUBBER (#02765500) |
| 20 | 91180721 | BUSHING (#91180721) |
| 21 | 98230636 | ALLEN BOLT (#98230636) |
| 22 | 95100144 | USE 95100141 (#95100144) |
| 23 | 92630206 | NUT (#92630206) |
| 24 | 98622316 | SCREW (#98622316) |
| 25 | 95004206 | WASHER (#95004206) |
| 26 | 02766200 | LIGHT COVER (#02766200) |
| 27 | 98872115 | ALLEN BOLT (#98872115) |
| 28 | 02768200 | GSKT (#02768200) |
| 29 | 02768400 | PROTECTION-DASH (#02768400) |
| 30 | 02781100 | PANEL (#02781100) |
| 31 | ||
| 32 | 02766500 | BOTTOM LITE COVER (#02766500) |
| 33 | 98872110 | ALLEN BOLT (#98872110) |
| 34 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 35 | 02768600 | LAMP HOLDER (#02768600) |
| 36 | 01782500 | IGNITION SWITCH (#01782500) |
| 37 | 66468115 | SECURITY BOLT (#66468115) |
| 38 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 39 | 02736800 | LOCK SET(#02736800) |
