1997 1999 V 10 Centauro 1000 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 01494000 | FORK BASE (#01494000) |
| 1 | 01494001 | FORK BASE C (#01494001) |
| 2 | 98622430 | SCREW (#98622430) |
| 3 | 02493100 | FORK CROWN B (#02493100) |
| 3 | 02493101 | FORK CROWN B (#02493101) |
| 4 | 30513400 | NUT (#30513400) USE 30513401 |
| 5 | 23943410 | CHROME PLUG (#23943410) |
| 6 | 01517700 | BADGE (#01517700) |
| 7 | 01490600 | FORK TUBE RH E (#01490600) |
| 8 | 01490700 | FORK TUBE LH E (#01490700) |
| 9 | 01530510 | NUT A (#01530510) |
| 10 | 01530511 | SPRING A (#01530511) |
| 11 | 01530512 | REG PLATE A (#01530512) |
| 12 | 01530513 | PLUNGER-COMP B (#01530513) |
| 13 | 01530514 | O RING A (#01530514) |
| 14 | 01530515 | COMP VALVE A (#01530515) |
| 15 | 01530516 | REBOUND VALVE A (#01530516) |
| 16 | 01530517 | PLUNGER-REBND B (#01530517) |
| 17 | 01530518 | NUT A (#01530518) |
| 18 | 01530519 | NEEDLE-COMP A (#01530519) |
| 19 | 01530520 | O RING (#01530520) |
| 20 | 01530521 | FORK ADJUSTER UNIT (#01530521) |
| 21 | 01530522 | O RING A (#01530522) |
| 22 | 01530523 | FORK LEG RH D (#01530523) |
| 22 | 01530561 | FORK LEG LH D (#01530561) |
| 23 | 01530524 | PLUG RH-COMP A (#01530524) |
| 23 | 01530562 | PLUG LH-REBND A (#01530562) |
| 24 | 01530525 | INNER FORK TUBE B (#01530525) |
| 25 | 01530526 | THREADED SLEEVE (#01530526) |
| 26 | 01530527 | BUSHING A (#01530527) |
| 27 | 01530528 | BUFFER NLA A (#01530528) |
| 28 | 01530529 | LOCK RING A (#01530529) |
| 29 | 01530530 | DAMPER ROD B (#01530530) |
| 30 | 01530531 | SPRING A (#01530531) |
| 31 | 01530532 | DAMPER RING A (#01530532) |
| 32 | 01530533 | CIRCLIP A (#01530533) |
| 33 | 01530534 | SPRING A (#01530534) |
| 34 | 01530535 | BALL A (#01530535) |
| 35 | 01530536 | CIRCLIP A (#01530536) |
| 36 | 01530537 | FORK SPRING C (#01530537) |
| 37 | 01530538 | SPACER 2.5MM A (#01530538) |
| 37 | 01530539 | SPACER 5.0MM A (#01530539) |
| 38 | 01530540 | HALF-COLLAR A (#01530540) |
| 39 | 01530541 | FORK SLEEVE D (#01530541) |
| 40 | 01530542 | BUSHING A (#01530542) |
| 41 | 01530543 | RETAINER A (#01530543) |
| 42 | 01530544 | SEAL RING (#01530544) USE 01530000 |
| 43 | 01530545 | SPACER A (#01530545) |
| 44 | 01530546 | RETAINING RING A (#01530546) |
| 45 | 01530547 | O RING (#01530547) |
| 46 | 01530548 | FORK TUBE D (#01530548) |
| 47 | 01530549 | WASHER A (#01530549) |
| 48 | 01530550 | BUSHING A (#01530550) |
| 49 | 01530551 | RETAINER A (#01530551) |
| 50 | 01530552 | WASHER (#01530552) |
| 51 | 01530553 | ALLEN BOLT A (#01530553) |
| 52 | 01530554 | O RING (#01530554) |
| 53 | 01530555 | RUBBER RING A (#01530555) |
| 54 | 01530556 | DAMPER ROD END A (#01530556) |
| 55 | 01530557 | NEEDLE-REBOUND A (#01530557) |
| 56 | 01530558 | ADJUSTER-REBOUN B (#01530558) |
| 57 | 01530559 | ADJ ROD-REBND A (#01530559) |
| 58 | 01530560 | 0-RING A (#01530560) |
| 59 | 98623430 | ALLEN BOLT (#98623430) |
| 60 | 01530563 | WASHER A (#01530563) |
