1997 2000 California EV (v11 EV Usa) 1100 Frame Electrical System
| Position | Part Number | Description |
|---|---|---|
| - | 2747901 | #04 Ground-battery lead (#2747901) |
| - | 3705540 | #28 Battery fixing snap (#3705540) |
| - | 3747130 | #01 Electrical system (#3747130) |
| - | 30705061 | BATTERY CLAMP A (#30705061) |
| 1 | ||
| 2 | 3747200 | #02 Dashboard cable Borletti (#3747200) |
| 3 | 30749760 | PLATE A (#30749760) |
| 4 | 98622312 | SCREW (#98622312) |
| 5 | 28576590 | CLIP A (#28576590) |
| 6 | 30922260 | CLIP A (#30922260) |
| 7 | 61013800 | SPRING WASHER (#61013800) |
| 8 | ||
| 9 | 19707100 | CAP (#19707100) |
| 10 | 30753160 | TAILLAMP HARNESS (#30753160) |
| 11 | 19748400 | CABLE (#19748400) |
| 12 | 30746360 | PLATE A (#30746360) |
| 13 | 98622316 | SCREW (#98622316) |
| 14 | 91551080 | GROMMET (#91551080) |
| 15 | 91180607 | SPACER (#91180607) |
| 16 | 30477101 | BRACKET RH (#30477101) USE 304771015 |
| 17 | 30477200 | BRACKET LH (#30477200) |
| 18 | 98622310 | ALLEN BOLT (#98622310) |
| 19 | 95100118 | WASHER (#95100118) |
| 20 | 92630206 | NUT (#92630206) |
| 21 | ||
| 22 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 23 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 24 | 17751200 | FLASHER HOLDER (#17751200) |
| 25 | 14609650 | TIE WRAP (#14609650) |
| 26 | ||
| 27 | ||
| 28 | 28704900 | STRAP (#28704900) |
| 29 | 3705000 | #29 Battery fixing plate (#3705000) |
| 30 | 12433000 | BUFFER-CENTER STAND STOP (#12433000) |
| 31 | 14461400 | GRIP (#14461400) |
| 32 | 95985351 | CARB VENT TUBE (#95985351) |
| 33 | 31750560 | FLASHER A (#31750560) |
| 34 | 31755660 | GROUND CABLE A (#31755660) |
