1997 2000 California EV (v11 EV Usa) 1100 Frame Exhaust Unit
| Position | Part Number | Description |
|---|---|---|
| - | 1121030 | #07 Flange (#1121030) |
| - | 3121000 | #07 Flange (#3121000) |
| - | 3122900 | #15 LH silencer, chromium plated (#3122900) |
| - | 3123000 | #10 RH silencer, chromium plated (#3123000) |
| - | 3123900 | #08 Expansion chamber (#3123900) |
| - | 14121200 | SPACER (#14121200) |
| - | 29120950 | RH EXHAUST PIPE 1100 CAL AND EV (#29120950) |
| - | 29120951 | LH EXHAUST PIPE 1100 CAL AND EV (#29120951) |
| 1 | 3120902 | #01 RH exhaust pipe, chr.plated (#3120902) |
| 2 | 3120903 | #02 LH exhaust pipe, chr.plated (#3120903) |
| 3 | 90718370 | EXHAUST GASKET (#90718370) |
| 4 | ||
| 5 | 17121061 | FLANGE (#17121061) |
| 6 | 14615901 | WASHER (#14615901) |
| 7 | 92781085 | CAP NUT (#92781085) |
| 8 | 29123951 | #22 Expansion chamber (#29123951) |
| 9 | 30123430 | EXHAUST CLAMP (#30123430) |
| 10 | 17123062 | MUFFLER RH SP (#17123062) |
| 11 | 3128600 | #11 RH plate (#03128600) |
| 12 | 95004208 | WASHER (#95004208) |
| 13 | 92630508 | NUT (#92630508) |
| 14 | ||
| 15 | 17122962 | MUFFLER LH SPNT (#17122962) |
| 16 | 3128700 | #16 LH plate (#03128700) |
| 17 | 3123400 | #17 Hose clamp (#3123400) |
| 18 | 98230835 | BOLT (#98230835) |
| 19 | 61270300 | WASHER (#61270300) |
| 20 | 98110007 | PLUG (#98110007) |
| 21 | 30109330 | COPPER WASHER (#30109330) |
