1997 2000 California EV (v11 EV Usa) 1100 Frame Front Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| - | 3434300 | #01 Front mudguard blank (#3434300) |
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | 304370602 | REAR FENDER (#304370602) |
| - | 89000348 | REAR FNDR CHERRY RED/WHITE (#89000348) |
| 1 | 89000347 | FRT FNDR CHERRY RED AND WHITE (#89000347) |
| 2 | 3435200 | #02 Front RH side profile ch.plate (#3435200) |
| 3 | 3435400 | #03 Front LH side profile ch.plate (#3435400) |
| 4 | 39922200 | PLATE (#39922200) |
| 5 | 3435300 | #05 Rear RH side profile ch.plate (#3435300) |
| 6 | 3435500 | #06 Rear LH side profile ch.plate (#3435500) |
| 7 | 3436400 | Rubber spacer (#3436400) USE 03436400 |
| 8 | 3436500 | #08 Cableguide (#3436500) |
| 9 | 3436300 | #09 Plate (#3436300) |
| 10 | 98052225 | BOLT (#98052225) |
| 11 | 92781053 | LOCK NUT (#92781053) |
| 12 | 3436600 | #02 Stabilization plate (#3436600) |
| 13 | 98230851 | ALLEN BOLT (#98230851) |
| 14 | 14615901 | WASHER (#14615901) |
| 15 | 98230622 | ALLEN SCREW (#98230622) |
| 16 | 66478610 | WASHER (#66478610) |
| 17 | 30576100 | BUSHING (#30576100) |
| 18 | 91551010 | GROMMET (#91551010) |
| 19 | ||
| 20 | 91551099 | RUBBER (#91551099) |
| 21 | 3439000 | #02 Screw (#3439000) |
