1997 2000 California EV (v11 EV Usa) 1100 Frame Front Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| - | 3490200 | #01 Front fork (#3490200) |
| - | 3550200 | Shock absorber (35500200) USE 03550200 (#3550200) |
| 1 | ||
| 2 | 30513400 | NUT (#30513400) USE 30513401 |
| 3 | 30516500 | WASHER (#30516500) |
| 4 | 14516700 | SHIM (#14516700) |
| 5 | 14517000 | RING DUST SEAL (#14517000) |
| 6 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 7 | ||
| 8 | 3531000 | #08 Plate (#3531000) |
| 9 | 17530260 | STEERING DAMPER (#17530260) |
| 10 | 98054325 | BOLT (#98054325) |
| 11 | 95000206 | WASHER (#95000206) |
| 12 | 92630206 | NUT (#92630206) |
| 13 | 98230621 | ALLEN BOLT(#98230621) |
| 14 | 61013800 | SPRING WASHER (#61013800) |
| 15 | ||
| 16 | 3541800 | #16 Pin (#3541800) |
| 17 | 95100431 | WASHER (#95100431) |
| 18 | 95100239 | WASHER (#95100239) |
| 19 | 95004208 | WASHER (#95004208) |
| 20 | ||
| 21 | ||
| 22 | 61270300 | WASHER (#61270300) |
