1998 2001 Nevada Club 750 Headlight Horn
| Position | Part Number | Description |
|---|---|---|
| 1 | 28740533 | HEADLAMP (#28740533) |
| 1 | 31740520 | USE 28740533 (#31740520) |
| 1 | 31740581 | H/L LENS ASSY (#31740581) |
| 1 | 31740582 | Headlight (#31740582) |
| 2 | 19740454 | HEADLIGHT RIM (#19740454) |
| 3 | 02740400 | OPTICAL GROUP CENTARO AND EV LENS, REFLECTOR, ETC. (#02740400) |
| 3 | 02740504 | Light assembly (#02740504) |
| 3 | 18740435 | H/L LENS ASSY (#18740435) |
| 3 | 31740420 | USE 18740435 (#31740420) |
| 4 | 93450232 | CAL H/L BULB 60/55 (#93450232) USE 292723 |
| 5 | 14756255 | CONNECTION (#14756255) |
| 6 | 02740458 | H/L BODY (#02740458) |
| 6 | 23740418 | SHELL (#23740418) |
| 7 | 19740404 | PLUG COVER (#19740404) |
| 8 | 95004208 | WASHER (#95004208) |
| 8 | 95004210 | WASHER (#95004210) |
| 9 | 98230831 | ALLEN BOLT A (#98230831) |
| 9 | 98231023 | ALLEN BOLT (#98231023) |
| 10 | 19740303 | SCREW (#19740303) |
| 11 | ||
| 12 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 13 | 31750665 | T/S LAMP RH (#31750665) |
| 13 | 31750666 | T/S LAMP LH (#31750666) |
| 14 | 19740302 | SCREW (#19740302) |
| 15 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 16 | 31753765 | SIGNAL LENS AMBER (#31753765) USE AP8124111 |
| 17 | 31743765 | HORN HIGH A (#31743765) |
| 18 | 31743766 | HORN LOW A (#31743766) |
| 19 | 98230816 | SCREW (#98230816) |
| 20 | 98612320 | ALLEN BOLT (#98612320) |
| 21 | 92660208 | FLANGED NUT (#92660208) |
| 22 | 31744265 | HORN MOUNT (#31744265) |
| 23 | 31744765 | HORN COVER A (#31744765) |
| 24 | 98230616 | SCREW (#98230616) |
| 25 | 95000206 | WASHER (#95000206) |
| 26 | 92630106 | NUT USE 92630707 (#92630106) |
| 27 | 31746981 | Headlight wiring w/harness (#31746981) |
| 28 | 91551105 | GROMMET (#91551105) |
| 29 | 31439881 | Spacer (#31439881) |
