1998 2002 Quota ES 1100 Front Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 30610326 | FRONT WHEEL ASSY. (#30610326) |
| 2 | 30611630 | FRONT SPOKE (#30611630) |
| 3 | 27611710 | SPOKE NIPPLE (#27611710) |
| 4 | 30620325 | BRAKE FLANGE A (#30620325) |
| 5 | 92204217 | BALL BEARING, REAR WHEEL (#92204217) |
| 6 | 39615201 | SPACER (#39615201) |
| 7 | 98052470 | BOLT (#98052470) |
| 8 | 14615901 | WASHER (#14615901) |
| 9 | 92630508 | NUT (#92630508) |
| 10 | 30613325 | BRAKE DISC-FRT C (#30613325) |
| 11 | 30611460 | ALLEN BOLT (#30611460) |
| 12 | 30616330 | SPACER (#30616330) |
| 13 | 30614127 | Front wheel spindle (#30614127) |
| 13 | 30614130 | #13 Front wheel spindle (#30614130) |
| 14 | 30615830 | AXLE WASHER (#30615830) |
| 15 | 92602316 | AXLE NUT (#92602316) |
| 16 | 12616101 | BALANCE WEIGHT (#12616101) |
| 16 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 16 | 12616103 | BALANCE WEIGHT (#12616103) |
| 17 | 30610826 | FRONT RIM (#30610826) |
| 18 | 62616800 | CAP (#62616800) |
| 18 | 93180216 | RUBBER PLUG (#93180216) |
