1998 2002 Quota ES 1100 Generator Regulator
| Position | Part Number | Description |
|---|---|---|
| 1 | 37712405 | ALTERNATOR (#37712405) |
| 2 | 37703805 | REGULATOR SERIES 2 (#37703805) |
| 3 | 30714201 | WASHER (#30714201) |
| 4 | 92603516 | NUT (#92603516) |
| 5 | 29711460 | FRONT COVER (#29711460) |
| 6 | 98620265 | ALLEN BOLT (#98620265) |
| 7 | 29217960 | WASHER (#29217960) |
| 8 | 90706178 | O RING (#90706178) |
| 9 | 37712306 | SPACER (#37712306) |
| 10 | 91600450 | WOODRUFF KEY (#91600450) |
| 11 | 29711960 | REAR COVER (#29711960) |
| 12 | 98622314 | ALLEN BOLT (#98622314) |
| 13 | 61013800 | SPRING WASHER (#61013800) |
| 14 | 29726461 | WIRING HARNESS (#29726461) |
| 15 | 30407430 | REGULATOR SUPPORT PLATE (#30407430) |
| 16 | 19007700 | RUBBER (#19007700) |
| 17 | 98610399 | SCREW (#98610399) |
| 18 | 95004206 | WASHER (#95004206) |
| 19 | 92630206 | NUT (#92630206) |
