1998 2002 Quota ES 1100 Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 30550225 | REAR SHOCK D (#30550225) |
| 2 | 30555225 | Screw (#30555225) |
| 3 | 37357706 | BOLT FRONT (#37357706) |
| 4 | 30562630 | REAR SUSP. LINK (#30562630) |
| 5 | 92252030 | ROLLER BEARING (#92252030) |
| 6 | 30561831 | BUSHING (#30561831) |
| 7 | 30562030 | PIVOT BOLT (#30562030) |
| 8 | 92660210 | NUT (#92660210) |
| 9 | 30560430 | SUSPENSION ROCKER (#30560430) |
| 10 | 30562931 | BUSHING (#30562931) |
| 11 | 30563030 | SPACER (#30563030) |
| 12 | 90402026 | SEAL RING (#90402026) |
| 13 | 30560825 | PIVOT PIN A (#30560825) |
| 14 | 92630410 | NUT A (#92630410) |
| 15 | 95100303 | SPACER A (#95100303) |
