1999 2000 California Special 1100 Front Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 03434300 | FRT FNDR BARE C (#03434300) |
| 1 | 03434331 | FRT FNDR BLACK D (#03434331) |
| 1 | 03434332 | FRT FNDR PEARL D (#03434332) |
| 1 | 03434333 | FRT FNDR BROWN D (#03434333) |
| 1 | 03434334 | FRT FNDR BLUE D (#03434334) |
| 1 | 03434335 | FRT FNDR MET BLACK 2ND SERIES (#03434335) |
| 1 | 03434336 | FRT FNDR WHITE 2ND SERIES (#03434336) |
| 1 | 03434351 | FRONT FNDR MATTE GREY (#03434351) |
| 1 | 89000340 | FRT FNDR YELLOW (#89000340) |
| 2 | 03435200 | MLDG RH FRT A (#03435200) |
| 3 | 03435400 | MLDG LH FRT A (#03435400) |
| 4 | 39922200 | PLATE (#39922200) |
| 5 | 03435300 | MLDG RH REAR (#03435300) |
| 6 | 03435500 | MLDG LH REAR (#03435500) |
| 7 | 03436400 | MOUNTING BLOCK (#03436400) |
| 8 | 03436500 | EYELET (#03436500) |
| 9 | 03436300 | PLATE (#03436300) |
| 10 | 98052225 | BOLT (#98052225) |
| 11 | 92781053 | LOCK NUT (#92781053) |
| 12 | 03436600 | FORK BRACE (#03436600) |
| 13 | 98230851 | ALLEN BOLT (#98230851) |
| 14 | 14615901 | WASHER (#14615901) |
| 15 | 98230622 | ALLEN SCREW (#98230622) |
| 16 | 95000205 | WASHER (#95000205) |
| 17 | 30576100 | BUSHING (#30576100) |
| 18 | 91551010 | GROMMET (#91551010) |
