1999 2001 California Jackal 1100 Dashboard
| Position | Part Number | Description |
|---|---|---|
| 1 | 02761500 | SPEEDO ASSY (#02761500) |
| 1 | 02762400 | SPEEDOMETER VEGLIA BRAND WHITE FACE (#02762400) |
| 2 | 23768310 | ANGLE DRIVE (#23768310) |
| 3 | 02762800 | TRIP RESET KNOB (#02762800) |
| 4 | 01760400 | SPEEDO CABLE (#01760400) |
| 4 | 97012300000 | SPEEDO CBL BRAIDED STAINLESS STEEL (#97012300000) NLA USE 12760400 |
| 5 | 28762540 | SPEEDO DRIVE ASSY. (#28762540) |
| 6 | 28763340 | DRIVE PINION (#28763340) |
| 7 | ||
| 8 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 9 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 10 | 17762200 | RUBBER BOOT (#17762200) |
| 11 | 02763000 | STUD A (#02763000) |
| 12 | 03764040 | INSTRUMENT SUPPORT (#03764040) |
| 13 | 02762301 | SPEEDO/TAC RUBBER GASKET (#02762301) |
| 14 | 97260415 | SECURITY BOLT A (#97260415) |
| 15 | 03762040 | CHROME LOWER CO (#03762040) |
| 16 | 98230512 | SCREW (#98230512) USE 831153 |
| 17 | 95005305 | WASHER (#95005305) |
| 18 | 02766000 | GAUGE MOUNT A (#02766000) |
| 19 | 02765500 | PANEL RUBBER (#02765500) |
| 20 | 91180721 | BUSHING (#91180721) |
| 21 | 98230640 | ALLEN BOLT (#98230640) |
| 22 | 95100124 | WASHER (#95100124) |
| 23 | 92660007 | NUT(#92660007) |
| 24 | 98622318 | SCREW (#98622318) |
| 25 | 95004206 | WASHER (#95004206) |
| 26 | 91180411 | SPACER (#91180411) |
| 27 | 99220332 | SCREW (#99220332) |
| 28 | 95000205 | WASHER (#95000205) |
| 29 | 91180413 | SPACER A (#91180413) |
| 30 | 03758140 | WARNING LIGHT (#03758140) |
| 31 | 03758040 | WARNING LIGHT H A (#03758040) |
| 32 | 03766540 | COVER (#03766540) |
| 33 | 99210316 | SCREW (#99210316) |
| 34 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 35 | 02768600 | LAMP HOLDER (#02768600) |
| 36 | 01782500 | IGNITION SWITCH (#01782500) |
