1999 2001 California Jackal 1100 Foot Rests
| Position | Part Number | Description |
|---|---|---|
| 1 | 03420330 | FRAME RAIL RH C (#03420330) |
| 2 | 03422130 | FRAME RAIL LH (#03422130) |
| 3 | 03446930 | COVER RH (#03446930) |
| 4 | 03447430 | COVER LH USE 0344 7410 (#03447430) |
| 5 | 98230621 | ALLEN BOLT(#98230621) |
| 6 | 93180115 | RUBBER A (#93180115) |
| 7 | 93231606 | RUBBER BUSHING (#93231606) |
| 8 | 03443930 | FOOTREST PLATE USE 03443960 (#03443930) |
| 9 | 98230822 | TOP SHOCK BOLT (#98230822) |
| 10 | 61270300 | WASHER (#61270300) |
| 11 | 03444230 | BUSHING (#03444230) |
| 12 | 14429500 | BOLT (ROD) (#14429500) |
| 13 | 95000213 | WASHER (#95000213) |
| 14 | 92602312 | NUT (#92602312) |
| 15 | 03423940 | MUFFLER BRKT A (#03423940) |
| 16 | 23440710 | RF FOOTPEG A (#23440710) |
| 17 | 03443740 | SUPPORT REAR NLA (#03443740) |
| 18 | 23441810 | LF FOOTPEG A (#23441810) |
| 19 | ||
| 20 | 95000208 | WASHER (#95000208) |
| 21 | 98054314 | SCREW (#98054314) |
| 22 | 61013800 | SPRING WASHER (#61013800) |
| 23 | 91180602 | SPACER (#91180602) |
| 24 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 25 | 03979340 | KIT CHROME LOWER FRAME COVER JACKAL (#03979340) |
| 26 | 92630208 | NUT (#92630208) |
| 27 | 98623635 | SCREW USE 9881 3635 (#98623635) |
| 28 | 98230826 | BOLT (#98230826) |
| 29 | 17444250 | SPACER (#17444250) |
| 30 | 95100414 | WASHER (#95100414) |
| 31 | 95021112 | WASHER (#95021112) |
| 32 | 92602512 | NUT (#92602512) |
| 34 | 98623640 | SCREW (#98623640) |
| 35 | 93180245 | RUBBER PLUG (#93180245) |
| 36 | 95000206 | WASHER (#95000206) |
| 37 | 30425260 | CROSS BRACE A (#30425260) |
| 38 | 98231022 | ALLEN BOLT A (#98231022) |
| 39 | 95021110 | WASHER (#95021110) |
| 40 | 00823931055 | GASKET (#00823931055) |
| 41 | 98230851 | ALLEN BOLT (#98230851) |
| 42 | 92630508 | NUT (#92630508) |
| 43 | 03443730 | FOOTREST MOUNT A (#03443730) |
| 44 | 23442210 | PIVOT PIN A (#23442210) |
| 45 | 95401215 | COTTER PIN (#95401215) |
| 46 | 03441130 | SPRING (#03441130) |
| 47 | 95100250 | SHIM (#95100250) |
| 48 | 95129130 | SHAKE PROOF WASHER (#95129130) |
