1999 2001 California Jackal 1100 Front Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 03610340 | FRONT WHEEL A (#03610340) |
| 2 | 92630508 | NUT (#92630508) |
| 3 | 92204220 | BEARING (#92204220) |
| 4 | 29615260 | SPACER (#29615260) |
| 5 | 03611640 | SPOKE (#03611640) |
| 6 | 03611741 | NIPPLE (#03611741) |
| 7 | 37613305 | BRAKE DISC FRT C (#37613305) |
| 8 | 98230825 | SCREW (#98230825) |
| 9 | 01614100 | AXLE-FRONT B (#01614100) |
| 9 | 03614101 | FRONT WHEEL SPINDEL (#03614101) |
| 10 | 03616340 | SPACER A (#03616340) |
| 11 | 95004219 | AXLE WASHER (#95004219) |
| 12 | 93704160 | AXLE NUT FRONT USE 93704160A HEX NUT (#93704160) |
| 13 | 12616101 | BALANCE WEIGHT (#12616101) |
| 13 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 13 | 12616103 | BALANCE WEIGHT (#12616103) |
| 14 | 03620340 | FLANGE B (#03620340) |
| 15 | 90272047 | CIRCLIP (#90272047) |
| 16 | 03584440 | COVER (#03584440) |
| 17 | 98230812 | ALLEN BOLT (#98230812) |
| 18 | 03615640 | SPACER A (#03615640) |
| 19 | 98052480 | SCREW (#98052480) |
| 20 | 14615901 | WASHER (#14615901) |
| 21 | 03610840 | FRONT RIM (#03610840) |
| 22 | 03605240 | AXLE CAP (#03605240) |
| 22 | 93180111 | RUBBER PLUG (#93180111) |
