1999 2001 California Jackal 1100 Optional Fixed Luggage Rack
| Position | Part Number | Description |
|---|---|---|
| 1 | 03999541 | BACKREST/HAND RAIL/RACK CHROME KIT (#03999541) |
| 2 | 03439000 | SCREW (#03439000) |
| 3 | 03468000 | CUSHION (#03468000) |
| 4 | 03468200 | CUSHION COVER A (#03468200) |
| 5 | 30466961 | COVER RH ( #30466961) (#30466961) |
| 6 | 30467361 | COVER LH (#30467361) |
| 7 | 61013800 | SPRING WASHER (#61013800) |
| 8 | 61270300 | WASHER (#61270300) |
| 9 | 92602206 | NUT (#92602206) USE STHN6MM |
| 10 | 95001206 | WASHER (#95001206) |
| 11 | 98230615 | ALLEN SCREW A (#98230615) |
| 12 | 98230619 | SCREW (#98230619) |
| 14 | 00823931080 | PVC GASKET (#00823931080) |
