1999 2001 California Jackal 1100 Optional Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 03669440 | KIT TWIN FRONT BRAKE DISC C D JACKAL (#03669440) |
| 1 | 03669441 | RH Front brake system (#03669441) |
| 2 | 98622530 | BOLT (#98622530) |
| 2 | 98623530 | BOLT (#98623530) |
| 3 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 4 | 95100332 | SHIM 0.5 MM (#95100332) |
| 4 | 95100333 | SHIM 0.8 MM (#95100333) |
| 5 | 30660125 | MASTER CYLINDER (#30660125) |
| 6 | 01652330 | CALIPER R H FRT (#01652330) |
| 6 | 03652300 | CALIPER-GREY (#03652300) |
| 7 | 03657100 | BRAKE HOSE (#03657100) |
| 7 | 03657101 | BRAKE LINE (#03657101) |
| 8 | 03436500 | EYELET (#03436500) |
| 9 | 17658260 | RUBBER RING (#17658260) |
| 10 | 03436400 | MOUNTING BLOCK (#03436400) |
| 11 | 03436300 | PLATE (#03436300) |
| 12 | 98052225 | BOLT (#98052225) |
| 13 | 92781053 | LOCK NUT (#92781053) |
| 14 | 37613305 | BRAKE DISC FRT C (#37613305) |
| 15 | 95990044 | Screw (#95990044) |
| 16 | 98230825 | SCREW (#98230825) |
| 17 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 18 | 03658400 | CLAMP (#03658400) |
