1999 2001 California Jackal 1100 Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 03630640 | REAR WHEEL A (#03630640) |
| 2 | 14615901 | WASHER (#14615901) |
| 3 | 92204220 | BEARING (#92204220) |
| 4 | 14634051 | SPACER (#14634051) |
| 5 | 30631160 | SPOKE SHORT (#30631160) |
| 6 | 12616101 | BALANCE WEIGHT (#12616101) |
| 6 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 6 | 12616103 | BALANCE WEIGHT (#12616103) |
| 7 | 30631430 | SPOKE, LONG (#30631430) |
| 8 | 03611740 | SPOKE NIPPLE (#03611740) |
| 9 | 01635700 | REAR BRAKE ROTOR - BLACK (#01635700) |
| 9 | 03635700 | REAR BRAKE DISCO DISCO FRENO POST. ORO (#03635700) USE 01635700 |
| 10 | 30611460 | ALLEN BOLT (#30611460) |
| 11 | 03633300 | AXLE - REAR (#03633300) |
| 12 | 01336800 | RUBBER BLOCK (#01336800) |
| 13 | 90706490 | O RING (#90706490) |
| 14 | 30335260 | DISC-CUSH DRIVE B (#30335260) |
| 15 | 14335303 | RING (#14335303) |
| 16 | 17335950 | LOCK PLATE (#17335950) |
| 17 | 61013800 | SPRING WASHER (#61013800) |
| 18 | 98054312 | BOLT (#98054312) |
| 19 | 03634100 | REAR AXLE SPACE A (#03634100) |
| 20 | 14634400 | RING (#14634400) |
| 21 | 29616450 | NUT A (#29616450) |
| 22 | 03632440 | FLANGE A (#03632440) |
| 23 | 90272047 | CIRCLIP (#90272047) |
| 24 | 17633550 | CUP (#17633550) |
| 25 | 98822430 | BOLT (#98822430) |
| 26 | 03630740 | REAR RIM D (#03630740) |
| 27 | 90271055 | CIRCLIP (#90271055) |
