1999 2001 V 11 Sport mandello 1100 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 01504530 | LH FORK CAP (#01504530) |
| 2 | 01530564 | O RING (#01530564) |
| 3 | 01530565 | FORK TUBE V11 SPORT (#01530565) |
| 3 | 01530584 | STEM HOLDER COMPL (#01530584) |
| 4 | 01517700 | BADGE (#01517700) |
| 5 | 01530566 | BUSHING (#01530566) |
| 6 | 01530567 | SPACER (#01530567) |
| 7 | 01530568 | WASHER (#01530568) USE 599504 |
| 8 | 27530584 | FORK SEAL V1100 SPORT,750 BREVA,LM (#27530584) |
| 9 | 30526261 | RETAINER (#30526261) |
| 10 | 01530571 | V11 SPORT DUST SEAL (#01530571) |
| 11 | 01530572 | NUT (#01530572) |
| 12 | 03530508 | CUP A (#03530508) |
| 13 | 01530574 | SPACER (#01530574) |
| 13 | 01530585 | PRELOAD SPACER (#01530585) |
| 14 | 01526630 | FORK SPRING (#01526630) |
| 15 | 01530575 | WASHER (#01530575) |
| 16 | 01530576 | RH INNER TUBE (#01530576) |
| 17 | 01530577 | LH INNER TUBE (#01530577) |
| 18 | 01526430 | RH shock absorber (#01526430) |
| 19 | 01526431 | LH DAMPER ROD (#01526431) |
| 20 | 01526330 | RH FORK VALVE (#01526330) |
| 21 | 01530578 | O RING (#01530578) |
| 22 | 03530522 | O RING (#03530522) |
| 23 | 01522530 | RH sleeve cpl. (#01522530) |
| 23 | 01522540 | FORKLEG RH (#01522540) |
| 24 | 01522630 | LH sleeve cpl. (#01522630) |
| 24 | 01522631 | LH sleeve cpl. (#01522631) |
| 24 | 01522640 | FORKLEG LH (#01522640) |
| 25 | 01493130 | UPPER TRIPLE CLAMP (#01493130) |
| 25 | 01493131 | FORK HEAD#2 (#01493131) |
| 25 | 01493140 | FORK HEAD MAT BLACK (#01493140) |
| 26 | 98622430 | SCREW (#98622430) |
| 27 | 98622325 | BOLT CHROME (#98622325) |
| 28 | 01530580 | Ring (#01530580) |
| 29 | 01494030 | Lower plate (#01494030) |
| 29 | 01494031 | Lower plate (#01494031) |
| 29 | 01494040 | Bottom plate, black (#01494040) |
| 30 | 01504531 | RH FORK CAP (#01504531) |
| 31 | 01526331 | LH FORK VALVE (#01526331) |
| 32 | 01490630 | RH FORK LEG ASSY. (#01490630) |
| 32 | 01490640 | FORK ARM RH COMPLETE (#01490640) |
| 33 | 01490730 | LH sleeve cpl. (#01490730) |
| 33 | 01490731 | LH FORK LEG COMP. W/ AXLE THRD (#01490731) |
| 33 | 01490740 | FORK ARM LH COMPLETE (#01490740) |
| 34 | 01999231 | FORK HD&BS#2 KIT (#01999231) |
