1999 2001 V 11 Sport mandello 1100 Saddle Rear Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 01460535 | Seat (#01460535) USE 01460560 |
| 2 | 02468100 | LOCK- SEAT (#02468100) |
| 3 | 01466430 | SEAT COVER BARE (#01466430) |
| 3 | 01466432 | Pass. saddle cover, green (#01466432) |
| 3 | 01466433 | SEAT COVER SILVER (#01466433) |
| 3 | 01466434 | SEAT COVER BLACK (#01466434) |
| 3 | 01466440 | SEAT COVER CANDY RED (#01466440) |
| 4 | 98230621 | ALLEN BOLT(#98230621) |
| 5 | 29577860 | PLASTIC WASHER (#29577860) |
| 6 | 01461530 | Seat Cover Pillow Ballabio (#01461530) |
| 7 | 92650006 | NUT (#92650006) |
| 8 | 01573032 | TAILPIECE GREEN 2ND SERIES (#01573032) |
| 8 | 01573033 | TAILPIECE SILVER 2ND SERIES (#01573033) |
| 8 | 01573034 | TAILPIECE BLACK 2ND SERIES (#01573034) |
| 8 | 01573040 | TAILPEICE MAT GREY (#01573040) |
| 8 | 01573135 | Rear fairing, blank (#01573135) |
| 9 | 93180721 | RUBBER BUSHING (#93180721) |
| 10 | 91120822 | NLA SPACER (#91120822) |
| 11 | 98230831 | ALLEN BOLT A (#98230831) |
| 12 | 01576530 | Nut with Clip (#01576530) |
| 13 | 91120818 | SPACER (#91120818) |
| 14 | 98230835 | BOLT (#98230835) |
| 15 | 01479630 | Document holder (#01479630) |
| 16 | 01900030 | V11 Sport/Mondello 99-01 Owners Manual Reprint (# 0190 0030R) (#01900030) |
| 17 | 01462430 | LOCK BRACKET (#01462430) |
| 18 | 98230620 | ALLEN BOLT (#98230620) |
| 19 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 21 | 95004206 | WASHER (#95004206) |
| 22 | 01923430 | DECAL V11SPT BLACK (#01923430) |
| 22 | 01923440 | DECAL ROSSO MANDELLO (#01923440) |
| 23 | 01923432 | DECAL KIT (#01923432) |
| 24 | 01468830 | SEAT LOCK CABLE (#01468830) |
| 25 | 02468600 | LATCH-SEAT (#02468600) |
| 26 | 98280410 | SCREW (#98280410) |
| 27 | 01923330 | Decal set (#01923330) |
| 27 | 01923332 | Decal set (#01923332) |
| 27 | 01923340 | DECAL KIT (#01923340) |
| 28 | 01736830 | LOCKS KIT (#01736830) |
