2001 2002 California Ev ev Touring 80 1100 Frame Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| - | ||
| - | ||
| - | ||
| 1 | ||
| 2 | 95008206 | WASHER (#95008206) |
| 3 | 155930171 | MOULDING-MTR A (#155930171) |
| 4 | 91551099 | RUBBER (#91551099) |
| 5 | 92650036 | Flanged Nut (#92650036) |
| 6 | 3437430 | #06 Ubolt under rear mudguard (#3437430) |
| 7 | 98223835 | Bolt, backrest pivot (#98223835) |
| 8 | 95005312 | Washer, 8.5x24x2 (#95005312) |
| 9 | 92787008 | NUT (#92787008) USE 860651 |
| 10 | 3438030 | #10 Splash guard (#3438030) |
| 11 | 98350325 | Hex Socket Screw (#98350325) |
| 13 | 92630107 | NUT NYLOC (#92630107) |
| 15 | 3578730 | #15 Spacer (#3578730) |
