2001 2002 California Ev ev Touring 80 1100 Front Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| 1 | 3660145 | #01 Front master cylinder (#3660145) |
| 2 | 03605645 | FRT BRAKE LEVER #03605645) (#03605645) |
| 3 | 03664045 | F/BRAKE LEVER MOUNT (#03664045) |
| 4 | 39663801 | DUST CAP (#39663801) |
| 5 | 03604845 | FRONT BRAKE LEVER PIN (#03604845) |
| 6 | 03659700 | HOSE GUIDE (#03659700) |
| 7 | 03749845 | MICRO SWITCH FRONT BRAKE (#03749845) |
| 8 | 98230412 | SCREW (#98230412) |
| 9 | 95021104 | WASHER (#95021104) |
| 10 | 03661145 | Master Cyl. Lid & Gasket (#03661145) |
| 11 | 95990028 | SCREW (#95990028) |
| 12 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 13 | 03657101 | BRAKE LINE (#03657101) |
| 14 | 03658430 | FASCETTA CORTA (#03658430) |
| 15 | 03658201 | BUSHING (#03658201) |
| 16 | 01652330 | CALIPER R H FRT (#01652330) |
| 17 | 98683530 | Bolt, Caliper (#98683530) |
| 18 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 19 | 95100332 | SHIM 0.5 MM (#95100332) |
| 19 | 95100333 | SHIM 0.8 MM (#95100333) |
| 20 | 01654630 | BRAKE PADS, PR (#01654630) |
| 21 | 01659230 | BLEEDING OVERHAUL UNIT (#01659230) |
| 22 | 01659130 | BLEEDING PAD PIN (#01659130) |
| 23 | 01659131 | FRT CALIPER SPRING (#01659131) |
| 24 | 95008206 | WASHER (#95008206) |
| 25 | 98230618 | ALLEN BOLT A (#98230618) |
