2001 2002 California Stone 1100 Cradle
| Position | Part Number | Description |
|---|---|---|
| 1 | 03420331 | FRAME RAIL RH (#03420331) |
| 2 | 03422130 | FRAME RAIL LH (#03422130) |
| 3 | 03446930 | COVER RH (#03446930) |
| 4 | 03447450 | FRAME COVER LH (#03447450) |
| 5 | 98370621 | BOLT (#98370621) |
| 6 | 95100123 | WASHER (#95100123) |
| 7 | 93231606 | RUBBER BUSHING (#93231606) |
| 8 | 03443930 | FOOTREST PLATE USE 03443960 (#03443930) |
| 9 | 03611445 | BOLT (#03611445) |
| 10 | ||
| 11 | 03444230 | BUSHING (#03444230) |
| 12 | 14429500 | BOLT (ROD) (#14429500) |
| 13 | 95000213 | WASHER (#95000213) |
| 14 | 92602312 | NUT (#92602312) |
| 15 | 03443545 | FOOTREST MOUNT RH (#03443545) |
| 16 | 23440710 | RF FOOTPEG A (#23440710) |
| 17 | 03446045 | FOOTREST MOUNT LH (#03446045) |
| 18 | 23441810 | LF FOOTPEG A (#23441810) |
| 19 | ||
| 20 | 93180117 | RUBBER A (#93180117) |
| 21 | 98084314 | BOLT (#98084314) |
| 22 | 03013800 | WAVE WASHER (#03013800) |
| 23 | 91180602 | SPACER (#91180602) |
| 24 | 98680435 | Screw (#98680435) |
| 25 | 03979350 | FRAME COVER KIT (03979350) (#03979350) |
| 26 | 92630508 | NUT (#92630508) |
| 27 | 98683635 | Screw 12X35 (#98683635) |
| 28 | 98681650 | Screw (#98681650) |
| 29 | 17444250 | SPACER (#17444250) |
| 30 | 95100414 | WASHER (#95100414) |
| 31 | 95021112 | WASHER (#95021112) |
| 32 | 92602512 | NUT (#92602512) |
| 34 | 98683640 | Screw 12X40 (#98683640) |
| 35 | 93180245 | RUBBER PLUG (#93180245) |
| 36 | 95005306 | WASHER (#95005306) |
| 37 | 30425260 | CROSS BRACE A (#30425260) |
| 38 | 98350522 | Bolt, Cradle Strap (#98350522) |
| 39 | 95021110 | WASHER (#95021110) |
| 40 | 00823931055 | GASKET (#00823931055) |
| 41 | 98230851 | ALLEN BOLT (#98230851) |
| 42 | 95129131 | Washer (#95129131) |
| 43 | 03443730 | FOOTREST MOUNT A (#03443730) |
| 44 | 23442210 | PIVOT PIN A (#23442210) |
| 45 | 95401215 | COTTER PIN (#95401215) |
| 46 | 03441130 | SPRING (#03441130) |
| 47 | 95100250 | SHIM (#95100250) |
