2002 2003 Nevada Base club 750 Crankshaft Cpl
| Position | Part Number | Description |
|---|---|---|
| 1 | 31064165 | #01 Crankshaft cpl. (#31064165) |
| 1 | 32064110 | Crankshaft Complete - Breva (#32064110) |
| 2 | 19065400 | PLUG (#19065400) |
| 3 | 27061585 | CON ROD ASSY B (#27061585) |
| 4 | 19062261 | CON ROD BOLT (#19062261) |
| 5 | 14615901 | WASHER (#14615901) |
| 6 | 27062060 | BEARING (#27062060) |
| 7 | 27065660 | BEARING (#27065660) |
| 8 | 27066560 | RR MAIN BEARING 1/2 (#27066560) |
| 9 | 27066460 | THRUST WASH (#27066460) |
| 10 | 20060220 | #10 Piston assy (#20060220) |
| 10 | 32060210 | Piston Assembly - Breva (#32060210) |
| 11 | 19060763 | PISTON RING A (#19060763) |
| 11 | 32060710 | Slot piston ring (#32060710) |
| 12 | 19061063 | PISTON RING-OIL A (#19061063) |
| 13 | 27061285 | WRIST PIN A (#27061285) |
| 14 | 27061385 | CIRCLIP (#27061385) |
| 15 | 27060860 | PISTON RING-MID A (#27060860) |
| 16 | 31060616 | #16 Pistonring set (#31060616) |
| 16 | 32060610 | PISTON RING SET (#32060610) |
| 17 | 27061885 | CON ROD BUSHING A (#27061885) |
| 18 | 19067700 | SCREW (#19067700) |
