2002 2003 Nevada Base club 750 F Fork R Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 31490284 | Front fork (#31490284) |
| 2 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 3 | 14494600 | CUP (#14494600) |
| 4 | 14516700 | SHIM (#14516700) |
| 5 | 14517000 | RING DUST SEAL (#14517000) |
| 6 | 31550282 | Shock absorber BITUBO (#31550282) |
| 7 | 31555281 | Pin (#31555281) |
| 8 | 95005309 | WASHER, 8.25x30x2 (#95005309) |
| 9 | 98822416 | SCREW (#98822416) |
| 10 | 23555280 | STUD (#23555280) |
| 11 | 95129181 | Washer (#95129181) |
| 12 | ||
| 13 | 92606210 | Nut (#92606210) |
| 14 | 98370825 | Hex Socket Screw (#98370825) |
| 15 | 31469281 | #09 Spacer (#31469281) |
| 16 | 90706092 | O RING (#90706092) |
| 17 | 31912760 | SHOCK WRENCH A (#31912760) |
| 18 | 98370614 | Screw (#98370614) |
| 19 | 31576183 | Spacer (#31576183) |
| 20 | 31497883 | Guard (#31497883) |
| 21 | 95005312 | Washer, 8.5x24x2 (#95005312) |
| 22 | 01517700 | BADGE (#01517700) |
